Product Details
Transformer oil coalescing dehydration purifier
Transformer oil coalescing dehydration purification systems are ideal for dehydrating, degassing and the removal of particulate contamination in lube oil, hydraulic fluid, transformer oil or insulating oils. In fact, several applications include oil reservoir purification in manufacturing facilities and power industries where oil can become contaminated. Furthermore, these systems are available in a variety of sizes with process flow rates ranging from 1.5 GPM to 100 GPM. As a result, oils can be restored to meet dryness levels of less than 30 ppm which improves bearing life. A filtration combination allows fluids to obtain the most stringent ISO cleanliness codes, hence improving oil performance and promoting fluid longevity.
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features
*.Strong ability to filter the impurity,strong capability of breaking emulsification. We adopt the high quality filter materials, which has a good function in anti-corrosive, thermos table, mechanical strength. Especially, the precision of eliminates impurity is high and the service life is long. Also, it has a large volume for storing the impurities.
*.The combination of coalescing separation and vacuum dewatering
*.Advanced dielectric condensation device
*.With H.P.M high polymeric absorbing material
*.Using the Three Dimensional Stereo-Evaporation technology, which can separate the odor and gas from the oil quickly .
*.This machine installs the new pressure protector, which can control the temperature automatically; also it can drain water on line by the water–separator device. So it is easy to control this machine.
Product applications
*.Purification of transformer oil and turbine oil
*.Water removal and impurity filtration of oil in hydraulic lubrication system
*.Access to hydraulic lubrication systems and comprehensively improve system cleanliness
