Product Details
This product is mainly aimed at the water ingress, emulsification and particles caused by industrial oil such as mechanical oil, hydraulic transmission oil, hydraulic oil, compressor oil, refrigeration oil, heat treatment oil, diesel oil, gasoline oil and other industrial oils during production, transportation and use. It is specially designed to deal with pollution, etc. The characteristics of this type of oil are: high viscosity, heavy moisture, and high cleanliness requirements. Through the special design of the vacuum separation system and impurity filtration system, the Enz oil filter can effectively filter out the moisture, gas, impurities and volatiles (gasoline, diesel, kerosene) in the oil, improve the oil quality and restore lubrication. Oil viscosity, flash point and performance. Ensure the normal operation of hydraulic system, power system and lubrication system. Therefore, the selection of lubricating oil series vacuum oil purifiers is an inevitable trend for industrial and mining enterprises to purify equipment oil.
Main body material: high carbon steel, 304 stainless steel can be customized
Working principle: Coalescence and demulsification, vacuum separation to remove water and degassing, step-by-step precision filtration to remove acid and impurities
Technical parameter
| Model | AOP-VS-*25 -**/*** | A0P-VS-*40 -**/*** | AOP-VS-*50 -**/*** | A0P-VS-*63 -**/*** | A0P-VS-*100 -**/*** | AOP-VS-*160 -**/*** |
| Flow rateL/min) | 25 | 40 | 50 | 63 | 100 | 160 |
| Working pressure(MPa) |
|
| 1.0 |
|
|
|
| Initial pressure loss (Mpa) |
|
| ≤0.2 |
|
|
|
| Coarse filtration(μm) |
|
| 100 |
|
|
|
| Fine filtration accuracy(μm) |
|
| 3、5、10、20、40 |
|
|
|
| Pressure differentials |
|
| 0.2Mpa |
|
|
|
| Operating temperature(°C) |
|
| 5-80 |
|
|
|
| Recommended viscosity(cSt) |
|
| 10- 760 |
|
|
|
| Voltage(V) | 1.1 | 2.2 | 3.0 | 3.0 | 4.0 | 5.5 |
| Weight(kg) | 160 | 232 | 240 | 265 | 400 | 540 |
| Dimensions(mm) | 1080x600x980 | 1200x600x980 | 1500x740x1020 | 1500x740x1020 | 1500x740x1020 | 1500x740x1020 |
Note: *- filtration series, A: primary filtration, B: secondary filtration
**- is filter's rating,such as 03 is 3 microns.
***- heating module, Omission: no heating module, R: heating module
****- oil pump, Omission: gear pump, LG: screw pump
Features
1. The machine adopts a multi-stage cartridge filter, which has a strong ability to filter out impurities. The coarse filter adopts a parallel large-flow washable filter element, which has high filtration efficiency and can remove a large amount of impurities in the oil; it can be cleaned online without delaying production; the precision filter element adopts the "gradually denser" technology, with high filtration accuracy and scale holding capacity. Large, high strength, long life, can remove fine particles in the oil; the whole machine design can choose the automatic backwash function, which not only improves the continuous working time of the equipment, but also ensures the service life of the filter element.
2. The water separation device adopts high-quality coalescence separation technology, and adopts a unique stainless steel folding cyclone degassing and dehydration separation tower to remove water quickly and efficiently; the self-developed jet degassing device can effectively remove the trace gas mixed in the oil. ; The condensate water automatic separation system is equipped with a strong air cooler, which can quickly condense and separate a large amount of water vapor and other gases discharged from the vacuum, so as to achieve the high-quality effect of one-time separation.
3. High-quality filter elements and connection sealing materials with corrosion resistance, high temperature resistance and high mechanical strength are used to meet the high temperature requirement for filtering high-viscosity lubricating oil; water-ring vacuum pump imported from Germany can be selected to use coolant (or water) ) is the lubricating medium, and it is not afraid of gas entering the vacuum pump, avoiding the trouble of frequent oil change of the rotary vane vacuum pump with oil as the medium.
4. The new heating device is adopted, the heating load is low, and the oil quality is prevented from aging.
5. The fuel injection prevention device adopts the photoelectric liquid level control method, which is sensitive and accurate in control, and can even sense the foam, and there is absolutely no fuel injection phenomenon.
6. Taking into account the characteristics of high-viscosity lubricating oil, Enz LV series vacuum oil filter for high-viscosity lubricating oil adopts pre-heating technology, so that the oil to be treated first enters the heating system when entering the equipment, which enhances the flowability of the lubricating oil. It is not easy to be blocked in the equipment and affect the normal use of the equipment.
Applications
Applicable oil: lubricating oil, hydraulic oil, mineral oil series, etc.
●To filter high-viscosity lubricants
●To fl-up high-viscosity lubricants
●The by-pass filtration for working hydraulic lubricants system
