Product Details
Hydraulic oil decolorization oil filter machine, hydraulic oil regeneration decolorization oil filter machine working principle:
Working method 1: When the equipment is working, the waste oil enters the primary filter through the oil inlet valve, and then is pumped into the agitator by the residual oil pump through the single pumping oil valve, and the primary filter filters out the larger particle impurities in the oil. Adjust the corresponding valve, and then the oil is pumped out of the agitator by the residual oil pump, and sent to the plate and frame pressure filter to filter out impurities and a small amount of water in the oil, and then send it back to the agitator.
Working mode 2: The oil passes through the primary filter, the residual oil pump, the plate and frame pressure filter, and the agitator.
Product parameters
| Technical item | Unit |
|
|
| Model |
|
|
|
|
| AD-30 | AD-50 | AD-100 | AD-150 | AD-200 | AD-250 | AD-300 |
| Flow | L/min | 30 | 50 | 100 | 150 | 200 | 250 | 300 |
| Average power | Kw/h | 7 | 7 | 9 | 9 | 12 | 15 | 15 |
| Heating power | Kw/h | 3 | 4.5 | 6 | 6 | 9 | 9 | 11 |
| Working vacuum | Mpa |
|
|
| -0.04～-0.098 |
|
|
|
| Working oil temperature | ℃ |
|
|
| 30～160 |
|
|
|
| Working pressure | MPa |
|
|
| ≤0.8 |
|
|
|
| With power supply | V |
|
|
| 380 |
|
|
|
| Noise | db(A) |
|
|
| ≤70 |
|
|
|
Features
1. Use special "decolorizing and deodorizing agent" chemical agent to eliminate the charge between polar particles in waste oil, make it aggregate into large particles of impurities, and separate out colloid, asphalt, and particulate impurities in the oil;
2. Strong dehydration and degassing ability. This machine uses a large-displacement vacuum pump to vacuum the system, which can remove the evaporated water vapor and other gases;
3. Advanced medium cooling endothermic condensing system;
4. Perfect vacuum degassing and dehydration system and exhaust gas filtration system can effectively remove moisture and harmful gases in oil;
5. The machine is equipped with perfect protection device. Through each executive element, the machine implements comprehensive protection for temperature, pressure, vacuum degree, power failure, etc., which can effectively prevent accidents and ensure the normal operation of the equipment;
6. Adopt high-precision filtration system with corrosion resistance, high temperature resistance, good mechanical strength and long service life;
7. The advanced heat transfer oil heating system has the characteristics of fast heating, stable oil temperature and uniform heating;
8. The machine has compact structure, reasonable layout and simple operation. This machine can be used for multiple purposes, and can meet the requirements of various personalized households.
9. The oil purification effect is obvious and intuitive, and the blackened and smelly oil can be processed into a clear and transparent oil without peculiar smell.
Applications
The machine can quickly remove harmful components in oil such as moisture, gas, impurities and volatiles (methanol, ethanol, acetylene, hydrogen, methane, ammonia gasoline) in lubricating oil, gear oil, hydraulic oil, etc. Oil quality, restore lubricating oil viscosity, and performance; can effectively ensure the normal operation of oil system equipment, reduce friction coefficient, improve lubrication effect, and avoid accidents. It is especially suitable for recycling all kinds of waste factory lubricating oil, rolling lubricating oil, etc. for regeneration, decolorization and reduction treatment, and also for other mineral waste oil regeneration, decolorization and reduction treatment.
