Product Details
The automatic slag discharge and decolorization oil purifier is innovatively designed by absorbing the advanced technology of similar products at home and abroad. It is cost-effective, and the oil purification process and equipment performance are at the level. It is a collection of vacuum flash drying, flocculation, adsorption and other purification technologies. It has the advantages of high degree of purification, fast oil purification, and oil quality protection. It can more efficiently remove water, impurities (solid impurities and oxidized impurities), hydrocarbons, colloids and chromosomes in the oil and other harmful substances, and restore the physical and chemical properties of the oil. Indicators to ensure long-term circulation of oil. It is mainly used for oil purification of hydraulic and lubricating systems to ensure the pollution degree of the system to the working medium, thereby improving the maintenance level of equipment, saving energy and reducing emissions.
Product parameters
| Technical item | Unit |
|
|
| Model |
|
|
|
|
| AD-30 | AD-50 | AD-100 | AD-150 | AD-200 | AD-250 | AD-300 |
| Flow | L/min | 30 | 50 | 100 | 150 | 200 | 250 | 300 |
| Average power | Kw/h | 7 | 7 | 9 | 9 | 12 | 15 | 15 |
| Heating power | Kw/h | 3 | 4.5 | 6 | 6 | 9 | 9 | 11 |
| Working vacuum | Mpa |
|
|
| -0.04～-0.098 |
|
|
|
| Working oil temperature | ℃ |
|
|
| 30～160 |
|
|
|
| Working pressure | MPa |
|
|
| ≤0.8 |
|
|
|
| With power supply | V |
|
|
| 380 |
|
|
|
| Noise | db(A) |
|
|
| ≤70 |
|
|
|
Features
1. The whole machine does not need filter element, filter cloth and filter paper, which greatly reduces the filtration cost.
2. The use of low temperature distillation will not destroy the oil quality.
3. Pure physical purification, the oil quality is restored as before, and the oil additives are not damaged.
4. Fully enclosed operation, environmental protection, no material loss.
5. The automatic slag discharge greatly reduces the labor intensity of workers and realizes continuous operation.
6. Adopt advanced indirect heating system, fast heating, stable oil temperature and uniform heating.
7. The advanced shower deodorization system is used to quickly and effectively remove various odors in the oil and protect the environment.
8. The oil purification effect is obvious and intuitive, which can refine the deteriorated, blackened and smelly oil into a clear, transparent and odorless national standard oil.
9. Extend the life of antioxidants and additives by removing oxides in the fluid.
Applications
This machine is applied to recover and purify various high-precision lubricating oil such as hydraulic oil, biodiesel oil, mechanical oil, polyester oil, coolant oil, gear oil, heat treatment oil, industrial oil, mineral oil, car oil, motor oil, engine oil and so on.
The machine can fast degas, dewater, and remove the impurity and the volatile matter (for example ethy1 alcohol, gasoline, ammonia and so on). Enhances the oil quality, restores the lubricating oil viscosity, augments the flash point and improves the operational performance. This machine suit for many lines, such as the mine, metallurgy, electric power, transportation, manufactures and so on.
