Product Details
Our vacuum waste oil decolorization machine utilizes the physical treatment, on the premise of without affecting the components and the performance of the oil, to rapidly remove the color, moisture, impurities and gases(acetylene, hydrogen, methane, etc) and other harmful ingredients, etc.
It can also be called purification process unit, oil purifier, used oil decoloration plant, vacuum oil decoloration machine, vacuum oil decolorization machine, vacuum oil purification system, vacuum oil purifier, waste oil decolorization machine and etc..
Product parameters
| Technical item | Unit |
|
|
| Model |
|
|
|
|
| AD-30 | AD-50 | AD-100 | AD-150 | AD-200 | AD-250 | AD-300 |
| Flow | L/min | 30 | 50 | 100 | 150 | 200 | 250 | 300 |
| Average power | Kw/h | 7 | 7 | 9 | 9 | 12 | 15 | 15 |
| Heating power | Kw/h | 3 | 4.5 | 6 | 6 | 9 | 9 | 11 |
| Working vacuum | Mpa |
|
|
| -0.04～-0.098 |
|
|
|
| Working oil temperature | ℃ |
|
|
| 30～160 |
|
|
|
| Working pressure | MPa |
|
|
| ≤0.8 |
|
|
|
| With power supply | V |
|
|
| 380 |
|
|
|
| Noise | db(A) |
|
|
| ≤70 |
|
|
|
Features
Fast decolorization, obvious effect, pure physical oil purification method, high degree of automation, simple and convenient operation, and movable. It can effectively remove pollutants in oil products, degas, dehydrate, remove mechanical impurities and severely oxidized sludge, asphaltenes, carbon residues, colloids, chromatin, etc.;
The various properties and physical and chemical indicators meet the relevant oil standards, and improve the cleanliness, flash point and emulsification performance of the oil.
The combination of coalescing separation and vacuum duplex 3D stereo-evaporation, eliminating water.
Deep and highly precise FH rectangle filtering system.
Our companys high molecule absorption material technology.
Regeneration device could effectively remove polar materials, such as acid. free carbon and so on.
Hydraulic lubricating oil treated by this machine contains low emulsification value, few water and impurities that it can be used repeatedly in the highly prcise hydraulic lubricating equipments at home and abroad.
Applications
Electric power, petroleum, chemical industry, metallurgy, mining, machinery, aviation, shipbuilding, railway and many other industries.
It is mainly used for the centralized regeneration of various red and blackened dirty oils and scrapped oils. various high-precision lubricating oil such as hydraulic oil, biodiesel oil, mechanical oil, polyester oil, coolant oil, gear oil, heat treatment oil, industrial oil, oils such as, mineral oil, car oil, motor oil, engine oil and so on.
