Product Details
For more than 20 years our corporation has been solving complex contamination problems across the refining, petrochemical and oil and gas industries. By applying our advanced filtration and separation technologies directly to the problem, we’re able to help operators reduce maintenance costs and minimize unscheduled shutdowns. Our machine is proven to efficiently filter contaminants from a wide variety of process and product streams, which can cause a multitude of costly operational and fluid quality problems.During the operation of hydraulic oil, mechanical oil, cooling oil and other lubricating oils, moisture, gas, volatile substances and impurities are inevitably mixed into the lubricating oil due to various reasons, which accelerates the oxidation of the oil and promotes foam, fouling and sludge. The formation of oil reduces the lubrication, heat dissipation, dispersion, cooling and other properties of oil. At the meantime, it causes corrosion and wear of metal parts, which affects the normal operation of hydraulic system, power system and lubrication system. This portable oil purification system, oil flling machine, high precision oil purifiers can quickly remove moisture, gas, impurities and volatiles from different oils. Improve oil quality, restore lubricating oil viscosity, flash point and performance. Ensure the normal operation of hydraulic system, power system and lubrication system. Our portable oil purification system, oil flling machine, high precision oil purifiers consists of several parallel pipes of precision oil filters, and is equipped with a pump motor, vacuum gauge, pressure gauge, suction filter, electromagnetic switch, iron frame, etc. to form a filtering system, and is equipped with wheels for easy mobile use , suitable for centralized filtration or all kinds of mechanical rotation filtration of the same oil, the filtration process is simple, the effect is nice, the price is affordable, and the scope is wide.
Technical parameter
| Model | AOP-S- 1R-* | AOP-S-2 R-* | AOP-S-3 R-* | AOP-S-4 R-* | AOP-S-5 R-* | AOP-S-6 R-* | AOP-S-7 R-* |
| Rated flow(L/min) | 3 | 6 | 9 | 12 | 15 | 18 | 24 |
| Rated pressure(MPa) | 1.6 |
| Mpa(MPa) | ≤0.25 |
| Coarse filter precision(μm) | 100 |
| Fine filter precision(μm) | NAS1638 3-6 Grade |
| Differential pressure | 0.8Mpa |
| Working temperature(°C) | 5-80 |
| Recommended viscosity(cSt) | 10-180 |
| Voltage(V) | AC380V(Three- phase)、50Hz |
| Motor power(kw) | 0.2 | 0.2 | 0.4 | 0.4 | 0.55 | 0.75 | 0.75 |
| Weight(kg) | 66 | 86 | 90 | 108 | 112 | 120 | 135 |
| Dimensions(mm) | 380x500x680 | 380x500x680 | 600x500x680 | 600x500x680 | 860x500x1000 | 1100x500x1000 | 100x500x1000 |
Features
Compact structure, small volume, light weight, easy to carry
Internal use filter element to filter, repeated use, save cost, not contaminated sites
Filtration precision, the product specifications can be free to choose according to need
According to the need can be made into explosion-proof type
Use patented technology to produce. Such as high-effctive separating separation tower, fuzzy control technology, dewatering and
degassing very effectively.
It can purify the losingefficient insulation oil and make the oil reach the new oil standard without power cut, changing the oill or
using filtering papers.
Have the function of flingg oil under vacuum condition.
Solve the problem of removing the acetylene.
The purifer has large route, strong capability of holding dirt and can be used for a long time.
This machine is small, light weight and convenient.
The ultrasonic dleaning function can be selected.
Have the multi-functions of centrifugal separation, molecular filter, condension de-watering and vacuum dry.
Have the functions of automatic burning protection and elimination foam.
Operate steady and the noise is speially low.
Applications
Lubricant oil filtration
Hydraulic lubrication system fltration during refueling
Bypass filration during operation of hydraulic lubrication system
Comprehensively improve the cleanliness of hydraulic lubrication system
Feed stocks to protect catalytic reactor beds
LPG, gasoline, diesel, and jet fuel final products
Many other contaminated products that can be
found in a variety of storage tanks in a plant
Amine (rich and lean)
Aromatic extraction solvents
Dehydration solvents
Sour water
Make-up water
Pre-filtration for liquid/liquid separations
