Product Details
Working Principle
When special oil filter for lubricating oil with high precision of impurity removal starts working, oil will be sucked into heater by vacuum pressure, then the oil will be heated and flow into primary filter, where the big impurities are separated. then, oil flows into vacuum separator, and flows through a special designed device, which makes per unit volume oil to produce a large surface area, lets the oil exposure in low humidity atmosphere, so the gas and water are separated from oil. the gas and separated water vapour forms as mixed gas, flows through water tank and cooler, condense into liquid and flows into water receiver, the residual gas is exhausted by vacuum pump. Oil flows through oil pump and into fine filter, where the tiny impurities are separated. If the oil is very dirty, or is high water content etc., you can purify the oil circularly for
several times, by which to remove the water and impurities completely.
Its function is that the special oil filter for lubricating oil with high precision of impurity removal can effectively remove gas, water, impurities and other contaminants from oil, and strongly emulsifed, by which to reduce oil's water content and impurity content, improve oil cleanness.
After treatment, the oil's technical parameters and properties are improved, prolonging oil service life and ensuring safety operation of industrial equipment.
Technical parameter
| Model | AOP-S- 1R-* | AOP-S-2 R-* | AOP-S-3 R-* | AOP-S-4 R-* | AOP-S-5 R-* | AOP-S-6 R-* | AOP-S-7 R-* |
| Rated flow(L/min) | 3 | 6 | 9 | 12 | 15 | 18 | 24 |
| Rated pressure(MPa) | 1.6 |
| Mpa(MPa) | ≤0.25 |
| Coarse filter precision(μm) | 100 |
| Fine filter precision(μm) | NAS1638 3-6 Grade |
| Differential pressure | 0.8Mpa |
| Working temperature(°C) | 5-80 |
| Recommended viscosity(cSt) | 10-180 |
| Voltage(V) | AC380V(Three- phase)、50Hz |
| Motor power(kw) | 0.2 | 0.2 | 0.4 | 0.4 | 0.55 | 0.75 | 0.75 |
| Weight(kg) | 66 | 86 | 90 | 108 | 112 | 120 | 135 |
| Dimensions(mm) | 380x500x680 | 380x500x680 | 600x500x680 | 600x500x680 | 860x500x1000 | 1100x500x1000 | 100x500x1000 |
Features
1.With the strong ability to filter the impurity, which can filter the particles complete.
2.It has the back fush system, which can clear impurities automatically.
3. Advanced dielectric condensation device
4.This machine installs the new pressure protector, which can control the temperature automatically; also it can drain water
on line by the water-separator device. So it is easy to control this machine.
5.We adopt the high quality filter materials, which has a good function in precision of eliminates impurity is high and the service
life is long. Also, it has a large volume for storing the impurities.
6.The unique degas and dewater system: Using the Stereo-Evaporation technical, which can separate the water and gas from the oil quick by the Multilevel water-oil separation technology
Applications
1.This machine is applied to purify lubricating oil, Hydraulic oil, Turbo oil, Coolant oil, Engine oil, Trucks oil, Mechanical oil, Heat treatment oil, Gear oil etc..
2.The oil purifer can be also used for treating some other oil such as used Cooking oil, Vegetable oil (Pretreatment or Post-treatment for producing bio diesel), etc.. Is widely used for various industries such as the mine, metallurgy, electric power, transportation, manufactures etc., where need to maintain lubricating systems.
