Product Details
This high solid content oil filter is especially suitable for occasions with high solid content. Especially suitable for waste oil regeneration and food oil clarification and filtration. The special filter material is used as the filter element, the thickness of the filter layer is 10-15 times that of the general filter material, the filtration efficiency is high, and it can effectively remove suspended solids, particles, rust, etc. It has a gradient void structure, and the filtration aperture is large outside and small inside, and has excellent deep filtration effect. Scientific design, compact structure, can withstand high filtration pressure. The rare deep mesh structure makes it have a very high dirt holding capacity. The components of the filter element are single, the chemical performance is stable, and it has good compatibility with the medium.
Technical parameter
| Model | AOP-G32 -*/** | AOP-G50 -*/** | AOP-G100 -*/** | AOP-G150 -*/** | AOP- -G200 -*/** |
| Rated flow(L/min) | 32 | 50
| 100 | 150
| 200 |
| Rated pressure(MPa) | 0.6 |
| Mpa(MPa) | ≤0.1
|
| Coarse filter precision(μm) | 180、120、 80
|
| Clarify filter precision(μm) | 5、10、20 |
| Fine filter precision(μm) | 3
|
Differential pressure
| 0.2MPa |
| Recommended viscosity(cSt) | 10-160 |
| Voltage(V) | AC 380V(Three - phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 3.0 | 5.5 |
Weight(kg) | 220 | 280 | 360 | 480 | 600 |
| Dimensions(mm) | 900x600x1080
| 1000x600x1080 | 1200x880x1280 | 1200x880x1520 | 1350x900x1870 |
Features
This oil purifier is suitable for the occasions with serious oil pollution and high solid content oil, especially suitable for the regeneration of waste oil and the clarification and fltration of food oil.
The filter element is made of a special filter material, and the thickness of the filter layer is 10-15 times of that of the general filter material. It is with high filtration efficiency and can effectively remove suspended solids, particles and rust in liquid. With a gradual aperture structure, the filter pore size is large outside and small inside, and has ecellent deep filtration effect. It has advanced design and compact structure so can bear very high fitration pressure. It has unique deep mesh structure so can hold very big volume dirty. The filter element has a single component with stable chemical performance So have good compatibility with the medium.
Applications
Clarification and filtration of large quantities of lubricants
The filtration for high-solid content lubricants
Regeneration and fltration of waste oil
