Lubricant Oil Purifier

Model Number:

Rated pressure(MPa) : 0.6

Coarse filter precision(μm) : 100

Differential pressure : 0.2Mpa

Working temperature(°C) : 5-80

Recommended viscosity(cSt) : 10-160

Get Quotation

Product Details

Hydraulic/lube mobile portable oil filter box

Our hydraulic/lube mobile portable oil filter box oil separation unit cleans almost all industrial oils to a super-clean levels NAS 4 even from dirtiness levels of NAS 99. Another prime advantage with these machines is that low vacuum dehydration attachment is inbuilt for fast removal of moisture/water from the oil. These machines are versatile in usage and can be used to clean oil in tanks (online) or in offline barrels and stand-by tanks. The benefit of such systems is that a single machine can be used to clean a number of oil tanks in a plant. However, the performance of the machine will depend largely on usage by factory personnel who will have to schedule it to different oil tank locations sincerely and religiously.

Technical parameter

Model

A0P-B3

2-*/**

AOP- B4

0-*/**

AOP- B5

0-*/**

AOP-B6

3-*/**

AOP-B10

0-*/**

Rated flow(L/min)32
405063100
Rated pressure(MPa)0.6
Mpa(MPa)≤0.02
Coarse filter precision(μm)100
Grade 1 filter precision( μ m)3、5、10、20
Grade 2 filter precision( μ m)3、S-W
Differential pressure0.2Mpa
Working temperature(°C)5-80
Recommended viscosity(cSt)10-160
Voltage(V)AC 380V(Three- phase)、50Hz
Motor power(kw)0.751.11.11.12.2
Weight(kg)135145150156182
Dimensions(mm)
950 x 560 x 900950 x 560 x 900950 x 560 x 900950 x 560 x 9001100 x 660 x 1000

Feartures

-Pre-filtration, fine filtration, double filtration area, long service life, and optional dewatering filter.

-The top design allows quick opening of the structure for easy replacement of the filter element.

-High quality whees, bearings, smooth running, no noise.

-The magnetic starter is equipped with thermal relay protection to protect the motor and is durable.

Applications

Oils which can be cleaned:

Hydraulic Oil

Turbine Oil

Gear Oil

Lubrication Oil

Engine Oil

Compressor Oil

Thermic Fluids

Transformer Oils

Honing Oil

Quenching Oil

Edible Oil

Flushing Fluids

Testing Oils

Water Glycols

Fire Resistant Fluids

Rust Preventive Oils

EDM Oil

Solvents etc.
