Lubricant Oil Purifier

Model Number:

Rated pressure(Mpa) : 0.34

Original pressure loss(Mpa) : ≤0.02

Coarse filtration accuracy(μm) : 40 meshes

Use temperature(°C) : 6~80

Recommended viscosity for use(cSt) : 10~160

Get Quotation

Product Details

Low-flow portable filtration systems

This catalog is our selection of low-flow portable filtration systems products for you. You are welcome to inquire about the detailed information of this product! There are many types of portable oil filters in our company, and there are subtle differences in different applications. Our company provides you with a full range of solutions.

Parameters

ModelAOP-6-*/**
AOP-10-*/**
AOP-16-*/**

Rated flow(L/min)

6
1016

Rated pressure(Mpa)

 0.34
Original pressure loss(Mpa)≤0.02

Coarse filtration accuracy(μm)

40 meshes

Fine filtration accuracy(μm)

3、 5、 10、 20、 40

Alarm differential pressure(MPa)

0.2MPa

Use temperature(°C)

6~80

Recommended viscosity for use(cSt)

10~160

Power supply(V)

AC380V three-phase, AC220V three-phase

Motor Power(kw)

0.180.250.35

Weight(kw)

131618

Dimensions(mm)

650x680x980
650x680x980
720x680x1020

Note: *- filter precision, such as 003 is 3 microns

**-Filter media, omitted: ordinary hydraulic oil; BH: water glycol; V: phosphate ester hydraulic oil.

Features

1. The machine is generally high-grade filtration, which can be made into multi-stage filtration according to customer needs.

Filters imported from abroad, the United States, Germany and Japan can be used, and of course you can also choose chinese filters.

2. Small size, light and flexible, easy to carry and operate.

3. The filter element is easy to clean. It can be cleaned by turning the T-shaped gong bolt above the filter.

4. It is widely used in oil pumping of various industrial oils filtration such as cutting fluids, oil injection and etc.

Applications

Suitable for conveying and filtering mechanical impurities of insulating oil, lubricating oil, various mineral and vegetable oils and other liquids.

It is suitable for oil change, oil replenishment, impurity filtration with small oil volume (such as machine tools, vehicles, fuel tanks, oil switches, transformers, conduits, etc.) ,chemical industry, laboratory, etc.

It is especially suitable for field and high-altitude operations, which can refuel and pump oil in the lubrication system.
