Lubricant oil coalescing dehydration purifier
The Lubricant oil coalescing dehydration purifier has precision filtration and high-efficiency dehydration.
The lubricant oil coalescing dehydration purifier employs advanced "coalescence separation" technology for dehydration, with high dehydration efficiency and strong capacity, especially for the separation of a large amount of water in the oil. It has the incomparable advantages of vacuum method and centrifugal method, and can break all the oil-water emulsification structure in the medium.
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features
Permanent Dispersion Media Inside Vacuum Tower - maximizes water extraction rates, eliminates the need for costly replacement of coalescer filter elements, and enables the system to operate effectively on high viscosity gear oils.
Variable Frequency Drive - enables operator to dial in the optimal flow rate, and enhances the system overall performance during cold start-ups, on higher viscosity oils, or when a restricted inlet condition exists.
Claw-Style Vacuum Pump - pulls deeper vacuum, higher CFM, and requires much less maintenance than other conventional vacuum pumps.
Single Utility - requires 480V, 3-Phase electric service only, not a chilled water supply.
System View Windows - enables operator to observe system operation and performance.
Plugged Filter Indicator Light - positive indication when the particulate removal filter element is plugged and needs to be changed.
Product applications
Mechanical processing, metallurgical industry, petrochemical industry, cement plant, electric power industry, iron and steel industry, paper industry, textile industry, purification of turbine oil and transformer oil; water removal and impurity removal of oil in hydraulic lubrication system; comprehensive access to hydraulic lubrication system Improve system cleanliness.
