Lubricating oil vacuum drying system
The vacuum hydraulic oil purifier is specially used to process high-precision oil products such as unqualified hydraulic oil and anti-wear hydraulic oil. Anti-oxidation stability, kinematic viscosity and flash point, restore the original characteristics of hydraulic oil, the vacuum hydraulic oil filter ensures the normal operation of power, lubrication and hydraulic systems, prolongs the service life of mechanical equipment, and is energy-saving and consumption-reducing Ideal product.
Product parameters
Model
|
AOP-1V-25
|
AOP-1V-32
|
AOP-1V-50
|
AOP-1V-100
|
AOP-1V-150
|
AOP-1V-200
|
Flow rate(L/min)
|
25
|
32
|
50
|
100
|
150
|
200
|
Working pressure(Mpa)
|
|
|
0.6
|
|
|
|
Rated vacuum(Mpa)
|
|
|
≤ - 0.095
|
|
|
|
Water content
|
|
|
5 - 30
|
|
|
|
Air content
|
|
|
≤0.2% |
|
|
|
Coarse filtration(μm)
|
|
|
100 |
|
|
|
Grade 1 filter rating(μm)
|
|
|
10、20 |
|
|
|
Grade 2 filter rating(μm)
|
|
|
3/5 |
|
|
|
Pressure differentials
|
|
|
00.2Mpa |
|
|
|
Voltage(V)
|
|
|
AC 380V(Three-phase)、50Hz |
|
|
|
Motor power(kw)
|
18 |
26 |
36 |
65 |
65 |
135 |
Weight(kg)
|
360
|
470
|
680
|
840
|
960
|
1500
|
Dimensions(mm) |
12500x920x1600
|
1350x980x1600
|
1500x1060x1800
|
1600x1080x2100
|
1800x1200x2200
|
2000x1200x2200
|
Note: * -is filter's rating,such as 03 is 3 microns.
**-is the suitable medium, Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate
hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
****-explosion-proof type: add F before type, Omission: normal type
Product features
This model has a number of patented technologies, which integrates vacuum drying, separation engineering technology, coagulation technology, gravity sedimentation method and precision filtration technology.
And the use of macromolecule filter material, hydrophilic and oleophobic filter material and membrane filtration technology multi-pole ultra-fine filtration to make your oil cleaner. The machine has a high degree of automation, complete interlock protection functions, easy and safe operation,can run continuously online or offline.
Product applications
It is suitable for various types and grades of various types of machinery oil, gear oil, refrigeration oil, hydraulic oil, compressor oil, quenching oil, internal combustion engine oil and other industrial oils to be purified after deterioration during use and transportation. . It can quickly remove moisture, gas, impurities, volatiles and acidic substances in lubricating oil, ensure the cleanliness, moisture, viscosity, flash point and other technical indicators of lubricating oil, and restore the performance of oil, thereby ensuring hydraulic pressure. The normal operation of the system, power system and lubrication system.
It is widely used in the purification treatment of various lubricating oils used in machinery, chemical industry, oil field, mining, metallurgy, electric power, transportation, manufacturing and other industries.
