Steam turbine oil coalescing purifier
Large-scale steam turbine speed control system widely uses phosphate ester fire-resistant oil as hydraulic working medium. Due to the influence of temperature, air impurities, moisture and operating conditions, the fire-resistant oil in operation will inevitably deteriorate. A thermal research institute in China has conducted in-depth research on the aging problem of fire-resistant oil in operation, and specially designed a fire-resistant oil on-line regeneration and dehydration device for this purpose. Reasonable configuration of regenerative filter element and precision particle filter has the characteristics of long service life and high filtration accuracy. In operation, as long as the on-line regeneration and dehydration device of anti-fuel oil is put into operation, the anti-fuel oil is regenerated, dehydrated and purified during operation, and each part of the filter element is replaced in time, so as to remove the harmful acid products, gum, colloid, etc. produced by the aging and deterioration of oil products. Moisture and mechanical impurities in oil, etc., to maintain long-term stability of oil performance. The oil performance index can fully meet the requirements of the safe operation of the speed control system equipment.
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features
- This machine adopts a number of innovative designs of advanced technology of similar equipment at home and abroad, and is at an advanced level in oil treatment technology and equipment performance. It has the characteristics of fast oil purification, high precision and low energy consumption.
- The whole machine is designed with a number of advanced technologies such as overpressure alarm shutdown system, overload protection system, filter point monitoring system, etc., which ensures the fully automatic and normal operation of the equipment.
- Optimized design of control interlock protection, overpressure alarm shutdown, etc. to ensure reliable operation of the equipment.
- It integrates precision filtration, coalescence and dehydration functions, and applies advanced "coalescence separation" technology, which has high dehydration efficiency and strong capacity, especially for light and low viscosity lubricating oil, hydraulic oil, turbine turbine oil, diesel oil, and kerosene. It can remove the oil-water emulsification structure in the medium; through the filtration of the particle filtration system, the cleanliness of the medium can be improved to above the national standard, without changing the physical and chemical properties of the oil, making the oil more efficient The use effect is better; the energy consumption is small, the operating cost is low, the continuous working performance is strong, and it is suitable for on-line or off-line operation.
- The ability to filter impurities is strong. The large-area and deep-level precision filter element can remove the fine particles in the oil, which can be used instead of the oil system cleaning device, so that the oil system with serious pollution can be restored to the cleanliness within the scope of use.
Product applications
1. Metallurgy: used for the filtration of the hydraulic system of rolling mills and continuous casting machines and the filtration of various lubricating equipment.
2. Petrochemical: separation and recovery of products and intermediate products in the process of oil refining and chemical production, and particle removal and filtration of oilfield well injection water and natural gas.
3. Textile: Purification and uniform filtration of polyester melt in the process of drawing, protection and filtration of air compressors, and degreasing and dehydration of compressed gas.
4. Electronics and pharmaceuticals: pre-treatment and filtration of reverse osmosis water and deionized water, pre-treatment and filtration of cleaning solution and glucose.
5. Electricity and nuclear power: gas turbine, boiler lubrication system, speed control system, bypass control system oil purification, water supply pump, fan and dust removal system purification.
6. Mechanical processing equipment: Papermaking machinery, mining machinery, injection molding machine and large precision machinery lubrication system and compressed air purification, tobacco processing equipment and spraying equipment dust recovery and filtration.
7. Railway internal combustion engine and generator: filtration of lubricating oil and oil.
8. Automobile engines and construction machinery: various hydraulic oil filters, diesel filters, and water filters for internal combustion engine air filters, fuel filters, construction machinery, ships, and trucks.
9. Various lifting and handling operations: from construction machinery such as hoisting and loading to special vehicles such as fire fighting, maintenance and handling, ship cranes, windlasses, blast furnaces, steel-making equipment, ship locks, opening and closing devices for ship doors, Elevating orchestra pits and elevating stages of theaters, various automatic conveying lines, etc.
10. Various operating devices that require force such as pushing, squeezing, pressing, shearing, cutting, and excavation: hydraulic presses, die-casting, forming, rolling, calendering, stretching, and shearing equipment of metal materials, plastic injection molding machines, plastic Chemical machinery such as extruders, tractors, harvesters and other agricultural and forestry machinery for felling and mining, excavation equipment for tunnels, mines and ground, steering gears for various ships, etc.
11. High-response, high-precision control: tracking and driving of artillery, stabilization of turrets, anti-swing of ships, attitude control of aircraft and missiles, high-precision positioning system of processing machine tools, driving and control of industrial robots, metal Sheet pressing, thickness control of leather slices, speed control of power station generators, high-performance vibration tables and testing machines, large-scale motion simulators and entertainment facilities with multiple degrees of freedom, etc.
12. Automatic manipulation and control of various work program combinations: combined machine tools, automatic machining lines, etc.
13. Special workplace: operating equipment in special environments such as underground, underwater, and explosion-proof.
