Turbine oil coalescence separation purification filtration unit
The turbine oil coalescence separation purification filtration unit of our company is an online oil purification device for water, steam turbine and other lubricating units. Based on our new series vacuum oil filter platform, this device is a bypass type oil treatment system with more powerful dehydration function than vacuum oil filter. The system adopts the new "coalescence separation" dehydration technology and vacuum separation technology. Combined, it integrates two functions of precision filtration and high-efficiency dehydration. It has strong demulsification, dehydration and impurity removal capabilities. Can quickly remove 100% of free water and up to 98% of dissolved water Can quickly remove 100% of free gas and up to 90% of dissolved gas. Make the quality indicators of the purified oil meet or approach the new oil standard and meet the requirements of use.
Product parameters
| Model |
A0P-D25 |
AOP-D50 |
A0P-D100 |
AOP-D150 |
A0P-D200 |
AOP-D400 |
| Rated flow(L/min) |
25 |
50 |
100 |
150 |
200 |
400
|
| Rated pressure(MPa) |
0.6 |
| Initial pressure loss (Mpa) |
≤0.1 |
| Filtered water content |
≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) |
10、20 |
Grade 2 filter rating( μ m) |
3、5 |
| Pressure differentials |
0.2Mpa |
| Working temperature(°C) |
25- 80 |
| Recommended viscosity(cSt) |
10-120 |
| Voltage(V) |
AC 380V(Three-phase)、50Hz |
| Motor power(kw) |
0.75 |
1.1 |
2.2 |
4 |
5.5 |
13
|
| Weight(kg) |
150 |
200 |
300 |
520 |
860 |
2860
|
| Dimensions(mm) |
1200x 800x1250 |
1350 x800x1400 |
1740x 980x1450 |
1800x1000x1540 |
1840x1050x1780 |
3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features:
*Using our company's new "coalescing vacuum two-system dehydration device" technology to achieve the perfect integration of three-dimensional evaporation technology and coalescing separation technology. The effect of dehydration and demulsification is 5 times that of ordinary vacuum oil filter.
* Multi-stage imported precision filter material is used to filter and remove fine particles in the oil step by step, with a large amount of dirt. And configure the filter filter pollution degree automatic detection function. Acids are formed by the interaction of water with metal particles produced in the system. Through effective impurity removal, water removal and degassing, air mixing is reduced and acid formation is prevented. Reduce the oxidation of oil to a minimum value, maintain the lubricating performance of the oil, improve the reliability of the system and prolong the service life of the oil.
*The system adopts low-density circulating carbon fiber heating technology and optimized pipeline design to prevent oil cracking and ensure uniform heating and stable oil temperature.
*. This machine adopts automatic constant temperature control, automatic liquid level control, automatic defoaming control, automatic pressure protection, etc., as well as sophisticated configuration, to ensure that the equipment will not spray oil during operation and run safely and stably.
*Overload protection, overpressure alarm shutdown protection, overload protection, oil shortage protection, fuel injection protection, phase sequence protection, etc. ensure the long-term reliable operation of the whole machine.
*Automatic design, and there are indications of oil temperature, pressure, vacuum degree, filter element pollution degree, running status, etc. The labelling is concise and clear.
*The design of the oil purification process of this machine is high-quality, and the connection with the fuel tank process can be matched with online processing or offline processing. It has a high degree of automation and can realize unattended operation. The device has a compact structure and is flexible and convenient to move. The machine features low noise, easy operation, long maintenance intervals and low energy consumption.
Product applications
Diesel, kerosene, gasoline and other light fuels, low-viscosity lubricating oil, turbine oil, hydraulic oil, anti-wear hydraulic oil, turbine oil, lubricating oil, aviation fuel, gasoline, kerosene, diesel oil, engine oil, etc.
