Product Details
Precision coalescing oil purifier
Working principle
The unqualified oil first enters the primary filtration, and the large particles of impurities are retained. The oil that removes the large particles of impurities is transported to the fine filter by the oil pump. After the small impurities are removed in the fine filter, it continues to enter the coalescing separator. In it, the principle of molecular separation technology is used to analyze the pressure of the oil, eliminate the intermolecular binding force, dissolve water, free water in the oil, quickly break the oil film and separate from the oil molecules and separate out; so far, the dehydration and removal of impurities are completed, so as to achieve Moisture and cleanliness requirements.
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features
● The equipment is equipped with a plate filter, using filter paper or filter cloth as the filter medium, with high precision and low cost.
● The water removal system and the impurity removal system can be used alone or at the same time. Suitable for filtering a variety of oils.
● Introduce international three-dimensional flash evaporation technology to maximize the evaporation area and evaporation space of oil in limited space, and have a blocking effect on oil to quickly and completely remove moisture and gas in oil.
● Equipped with automatic constant temperature control system, automatic liquid level control system, automatic defoaming control system, automatic pressure protection system, heating protection system, so as to achieve the purpose of man-machine separation.
● Adopt well-known brand gear oil pump, low speed operation, low noise and small shearing effect on oil.
● Internationally advanced infrared heating system and optimized heating device design make the oil heated evenly and the heating speed is fast, without causing partial carbonization of the oil, effectively preventing the generation of harmful gases during the oil filtering process.
● Adopt advanced strong air cooling technology and medium condensing device, which can quickly cool the water vapor separated from the oil and prolong the service life of the equipment.
● The digital display intelligent temperature controller realizes precise control, and controls the heating system to run automatically according to the set temperature. There is no turbulence at the critical point of heating, and the heating is stable and balanced.
● Equipped with leakage and overload shutdown device to protect the motor.
● Equipped with phase sequence, phase loss protection functions, and sudden shutdown safety control.
● The machine has advanced technological design, simple operation and convenient maintenance.
● The equipment is made of carbon steel and stainless steel, and the color of the machine can be customized according to customer requirements.
● Oil pumps, vacuum pumps, motors, filter elements, electrical components and instruments are available from domestic brands, joint venture brands and international imported brands.
● According to the user's needs, it can be equipped with PLC intelligent control, touch screen operation, and dynamic display.
● Equipment styles include fixed, open, frame, semi-enclosed, fully enclosed, and large trailers.
Product applications
Mechanical processing, metallurgical industry, petrochemical industry, cement plant, electric power industry, iron and steel industry, paper industry, textile industry, purification of turbine oil and transformer oil; water removal and impurity removal of oil in hydraulic lubrication system; comprehensive access to hydraulic lubrication system Improve system cleanliness.
