Vacuum oil filter cart
Vacuum oil filter cart
Vacuum oil filter cart

Vacuum oil filter cart

Turbine Oil Purifier

Model Number:

Working pressure(Mpa) : 0.6

Rated vacuum(Mpa) : ≤ - 0.095

Water content : 5 - 30

Air content : ≤0.2%

Coarse filtration(μm) : 100

Get Quotation

Product Details

Vacuum oil filter cart

Vacuum oil filter cart is widely used in the field treatment of production oil, such as transformer oil, turbine oil, machine tool lubricating oil, switch oil, transformer oil and other oil. After the industrial oil has been used for a period of time, water pollution and particle pollution will appear in the oil, which will accelerate the deterioration of the oil, accelerate metal fatigue, increase the wear of hydraulic components, and cause the insulating oil to lose its dielectric strength. The vacuum oil filter cart can dynamically process the oil without stopping production, reduce production and operation costs, burn and discharge waste oil, and avoid the resulting environmental pollution. At present, there are many manufacturers producing such oil purifiers in our country.

Product parameters

 Model
AOP-1V-25
AOP-1V-32
AOP-1V-50
AOP-1V-100
AOP-1V-150
 AOP-1V-200
 Flow rate(L/min)
25
32
50
100
150
200
Working pressure(Mpa)


 0.6



Rated vacuum(Mpa)


≤ - 0.095



Water content


5 - 30



Air content


≤0.2%


Coarse filtration(μm)


100


Grade 1 filter rating(μm)


10、20


Grade 2 filter rating(μm)


3/5


Pressure differentials


00.2Mpa


Voltage(V)


AC 380V(Three-phase)、50Hz


Motor power(kw)
18 26 36 65 65 135
 Weight(kg)
360
470
680
840
960
1500

Dimensions(mm)

12500x920x1600
1350x980x1600
1500x1060x1800
1600x1080x2100
1800x1200x2200
2000x1200x2200

Note: * -is filter's rating,such as 03 is 3 microns.

**-is the suitable medium, Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate

hydraulic fluid

***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.

****-explosion-proof type: add F before type, Omission: normal type

Product features

Accepts M-Class vacuums and wall-mounted Division 1 vacuum.

Vacuum unit mounts and locks to cart for stability, and may be quickly removed for everyday maintenance.

Tools, vacuum hoses, air lines and electric cord mount directly to cart, for convenient accessibility. Tools and accessories sold separately.

Includes four shelves for handy storage of tools, accessories, abrasives and more. Shelves are protected by lockable door for added security.

Cart comes equipped with easy-glide steering casters to effortlessly transport vacuum unit, even on irregular surfaces.

Durable powder-coated finish.

Product applications

Thermal power and nuclear power, petrochemical, electronics and pharmaceuticals, automotive engines and construction machinery, metallurgy, textiles, mechanical processing equipment.
