Product Details
Vacuum oil filtration and dehydration system are designed to remove 100% of free and emulsified water and at least 90% of dissolved water from petroleum and synthetic-based fluids. And, VAC systems remove 100% of free gases and least 90% of dissolved gases. What makes a Des-Case VAC system most unique is it’s designed for continuous, unattended duty and doesn’t require vacuum tower maintenance or costly coalescing filter element replacements―the tower is completely sealed and uses permanent dispersion media.
By maintaining absolute fluid cleanliness, you can dramatically increase the life of critical electric transmission components, maintain dielectric strength and condition of insulation, minimize downtime and maximize profitability.
Product parameters
Model
|
AOP-1V-25
|
AOP-1V-32
|
AOP-1V-50
|
AOP-1V-100
|
AOP-1V-150
|
AOP-1V-200
|
Flow rate(L/min)
|
25
|
32
|
50
|
100
|
150
|
200
|
Working pressure(Mpa)
|
|
|
0.6
|
|
|
|
Rated vacuum(Mpa)
|
|
|
≤ - 0.095
|
|
|
|
Water content
|
|
|
5 - 30
|
|
|
|
Air content
|
|
|
≤0.2% |
|
|
|
Coarse filtration(μm)
|
|
|
100 |
|
|
|
Grade 1 filter rating(μm)
|
|
|
10、20 |
|
|
|
Grade 2 filter rating(μm)
|
|
|
3/5 |
|
|
|
Pressure differentials
|
|
|
00.2Mpa |
|
|
|
Voltage(V)
|
|
|
AC 380V(Three-phase)、50Hz |
|
|
|
Motor power(kw)
|
18 |
26 |
36 |
65 |
65 |
135 |
Weight(kg)
|
360
|
470
|
680
|
840
|
960
|
1500
|
Dimensions
(mm) |
12500x920x1600
|
1350x980x1600
|
1500x1060x1800
|
1600x1080x2100
|
1800x1200x2200
|
2000x1200x2200
|
Note: * -is filter's rating,such as 03 is 3 microns.
**-is the suitable medium, Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate
hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
****-explosion-proof type: add F before type, Omission: normal type
Product features
Heavy-duty, industrial construction
Lifting eyes, full drip pan, fork lift slots, heavy-duty casters
Basket strainer included to protect system
No vacuum tower maintenance needed
Designed for continuous, unattended duty
PLC controller is standard on all systems
Variable Frequency Drive (VFD) is standard on all systems
Higher water removal efficiency—as low as 20ppm for industrial systems
No water supply needed
Breather on the vacuum control inlet
Several warning indicators and safety alarms, such as low flow and high pressure
No replacement of coalescing elements needed, reducing maintenance cost
Features a low maintenance, continuous-duty pump
NEMA 4 electrical ratin
Product applications
Hydraulic systems filtration
Steam turbine lube systems filtration
Filtration of almost any industrial equipment containing oil
