Product Details
This oil filter is especially suitable for occasions with high solids content. Especially suitable for waste oil regeneration and food oil clarification and filtration. The special filter material is used as the filter element, the thickness of the filter layer is 10~15 times that of the general filter material, and the filtration efficiency is high, which can effectively remove suspended solids, particles, rust, etc. It has a gradient void structure, and the filtration aperture is large outside and small inside, and has excellent deep filtration effect. Scientific design, compact structure, can withstand high filtration pressure. The unique deep mesh structure makes it have a very high dirt holding capacity. The components of the filter element are single, the chemical performance is stable, and it has good compatibility with the medium.
Technical parameter
| Model | AOP-G32 -*/** | AOP-G50 -*/** | AOP-G100 -*/** | AOP-G150 -*/** | AOP- -G200 -*/** |
| Rated flow(L/min) | 32 | 50
| 100 | 150
| 200 |
| Rated pressure(MPa) | 0.6 |
| Mpa(MPa) | ≤0.1
|
| Coarse filter precision(μm) | 180、120、 80
|
| Clarify filter precision(μm) | 5、10、20 |
| Fine filter precision(μm) | 3
|
Differential pressure
| 0.2MPa |
| Recommended viscosity(cSt) | 10-160 |
| Voltage(V) | AC 380V(Three - phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 3.0 | 5.5 |
Weight(kg) | 220 | 280 | 360 | 480 | 600 |
| Dimensions(mm) | 900x600x1080
| 1000x600x1080 | 1200x880x1280 | 1200x880x1520 | 1350x900x1870 |
Features
(1) The oil filter truck mainly adopts the mechanical filtration method, and gradually reduces the density of the filter screen to achieve the purpose of improving the filtration accuracy. It can be seen that during the working process of the equipment, the stage filtration is easy to be blocked by impurities, which will occur at this time. Oil in is less than oil out. Treatment method: Remove the upper cover of the first-stage filter, take out the filter screen, and clean it with the same type of cleaning oil, and then the work can be restored.
(2) If the lift is too high during the refueling process, the temperature of the motor will rise rapidly and the noise of the oil pump will increase. Treatment method: work according to the specified head; intermittent work.
(3) The noise of the oil pump increases abnormally: the treatment method: check whether the connecting shaft of the oil pump is concentric; the hydraulic system works for a long time.
Applications
●Filtering of high solids all types food oils
●Clarification and filtration of food oil
●Regeneration and filtration of waste oil
