Carton type purifier filtration device for rail oil
Carton-type purifier filtration device for rail oil is a hydraulic oil high-efficiency filtration type oil purifier.
The machine has multi-stage pressureless reverse osmosis filtration with a filtration accuracy of 0.1~7 microns! Remove water without heating!
Machine principle:
Multi-level: According to the size of different impurities, the characteristics of different pollutants, different filter material materials and prices, the purification levels are distributed in sequence.
No pressure: add a return pipe to decompress the part from the oil pump to the filter element, so that the oil can penetrate into each filter element in the state of no pressure and slight pressure, prolong the life of the filter element and improve the efficiency of purification.
Reverse osmosis: The reverse osmosis filter element is made of three materials: glass fiber, lipophilic and hydrophobic material, and precision membrane. Glass fiber is the main material of the precision filter element; the lipophilic and hydrophobic material can separate the oil molecules from the water, so that the water molecules condense into large water droplets. It can be left on the outside of the filter element and fall on the bottom of the filter bucket due to its weight to discharge regularly.
Technical parameter
| Model | A0P-B32-*/** | AOP- B40-*/** | AOP- B50-*/** | AOP-B63-*/** | AOP-B100-*/** |
| Rated flow(L/min) | 32
| 40 | 50 | 63 | 100 |
| Rated pressure(MPa) | 0.6 |
| Mpa(MPa) | ≤0.02 |
| Coarse filter precision(μm) | 100 |
| Grade 1 filter precision( μ m) | 3、5、10、20 |
| Grade 2 filter precision( μ m) | 3、S-W |
| Differential pressure | 0.2Mpa |
| Working temperature(°C) | 5-80 |
| Recommended viscosity(cSt) | 10-160 |
| Voltage(V) | AC 380V(Three- phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 1.1 | 1.1 | 2.2 |
| Weight(kg) | 135 | 145 | 150 | 156 | 182 |
Dimensions(mm)
| 950 x 560 x 900 | 950 x 560 x 900 | 950 x 560 x 900 | 950 x 560 x 900 | 1100 x 660 x 1000 |
Features
Four characteristics of our carton-type purifier filtration device for rail oil pressureless reverse osmosis purification technology
1. Low cost: The osmotic technology allows impurities and water to be discharged outside the filter material. The filter element can purify 50 tons of hydraulic oil in the system, and the cost of purifying each liter of oil is less than 0.1 yuan.
2. High efficiency: According to the degree of dirty oil, the oil product precision after circulating purification is NAS5-9.
3. Safety: In addition to the inlet and outlet oil-pipes, the machine also adds a return pipe, and the oil that cannot penetrate enough is exported from the return pipe, and the whole machine is safer without pressure-force.
4. Demulsification: The filter material has the oil-water separation function, which can separate the water in the oil without heating to avoid destroying the oil quality, reaching below 70PPM.
Applications
Suitable oil types:
Oil, hydraulic oil, lubricating oil, transformer oil, turbine oil, gear oil, rail oil, cutting oil, quenching oil, stamping oil, anti-rust oil, spark oil, etc.
