Product Details
Mobile/Moveable hydraulic oil purifier
Mobile/Moveable hydraulic oil purifier is a handy offline filter trolley suitable for rinsing and filtering petroleum-based liquids.
This portable filtration machine is suitable for quickly, conveniently and economically removing particulate contamination or water from your lube oil, hydraulic oil or fuels.
Preventive and proactive maintenance in an economical way. The oil or fuel is pumped through a 10μm excellment fine filter elements as standard for optimum cleanliness. However, if you want to remove water, a water absorption element is available or if you have specific requirements, please contact us for a custom-made offer.
Parameters
| Model |
AOP-B25
-*/** |
A0P-B32
-*/** |
A0P-B40
-*/** |
A0P-B50
-*/** |
A0P-B63
-*/** |
A0P-B100
-*/** |
A0P-B150
-*/** |
| Rated flow(L /min) |
25 |
32 |
40 |
50 |
63 |
100 |
150 |
| Rated pressure(MPa) |
0.6 |
| Mpa(MPa) |
≤0.02 |
| Coarse filter precision(μm) |
100 |
| Grade 1 filter rating(μm) |
10、20、40 |
| Grade 2 filter rating(μm) |
3、5、 10、S-W |
| Differential pressure |
0.2Mpa |
| Working temperature(°C) |
5-80 |
Recommended viscosity(cSt) |
10- 160 |
Voltage(V) |
AC 380V(Three-phase)、50Hz |
| Motor power(kw) |
0.55 |
0.75 |
1.1 |
1.1 |
1.5
|
2.2
|
3.0
|
| Weight(kg) |
46
|
78
|
90
|
96
|
102
|
120
|
160
|
| Dimensions(mm) |
520x350 x950
|
520 x350x950
|
720x 680 x 1020
|
720 x<680 x 1020
|
720 x 680x 1020
|
720x 750x 1020
|
720x750x 122
|
This oil filter includes a special gear pump driven by a motor. It has the characteristics of low field sound, strong self- priming ability, and stable operation.
The high-pressure pipeline is equipped with overflow protection device a. It can efetively protect the safety of the hydraulic system.
Use thermal relay protection to prevent the motor from being damaged due to motor overload.
The coarse filter at the suction port protects the oil pump and extends the service life of the main flter.
There is a two-stage fine filter behind the pump to make the oil quickly reach a high degree of cleanliness.
Different precision for the fine filter can be chosen according to the dffrent needs of users to achieve the required results.
The primary flter can filter out larger particles and impurities, and the secondary flter can fiter out fine particles or water.
The oil filter housing adopts a quick- opening structure. No special tools are needed to quickly open the upper cover and replace the flter element.
The panel is equpped with a pressure gauge, which continuously indicates the operating status of the system and the pollution degree of the flter element during work.
Features
-Can purify the tiny and fine mechanical impurities oil to remove the harmful materials.
-A prior choice for high precision removing impurities.
-With the function of oil filling & oil drawing.(for equipments required small quantity of oil)
-No heating system, saving energy.
-The filter microns can be customized design for different quality oils.
-It can be used for any oil which needs to remove particles.
-It’s characterized by simple structure, easy operation, low operation cost, ect.
Applications
Mobile/Moveable hydraulic oil purifier effectively purify the tiny and fine mechanical impurities oil, enabling it to be a prior choice of power industry, petroleum,chemical, metallurgy, mechanics and railway enterprises for oil filtration, oil filling, oil drawing.
