Vertical tramp oil separator coalescing filter system

Our vertical tramp oil separator coalescing filter system will remove tramp oils from your coolant or wash water, thereby, both extending the life of your cleaner and improving the wash quality.

The coalescer works by first separating the oil droplets from the wash water or coolant. These small droplets are then attracted to the coalescing media where they accumulate and combine with other droplets until they are big enough to flow to the surface where they can be removed.

These separators come in several sizes from the TS-3 portable system to the model 450/5 which has a maximum batch capacity of 450 gallons.


Product parameters

ModelA0P-D25AOP-D50A0P-D100AOP-D150A0P-D200AOP-D400
Rated flow(L/min)

25

50

100

150

200

400
Rated pressure(MPa)                                                                                                         0.6
Initial pressure loss (Mpa)                                                                                                       ≤0.1
Filtered water content                                                                                                       ≤100
Coarse filtration( μ m)


                                                                                                        100

Grade 1 filter rating( μ m)                                                                                                     10、20


Grade 2 filter rating( μ m)

                                                                                                       3、5
Pressure differentials                                                                                                    0.2Mpa
Working temperature(°C)                                                                                                     25- 80
Recommended viscosity(cSt)                                                                                                     10-120
Voltage(V)                                                                                  AC 380V(Three-phase)、50Hz
Motor power(kw)

0.75

1.1

2.2

4

5.5

13
Weight(kg)

150

200

300

520

860

2860
Dimensions(mm)1200x 800x12501350 x800x14001740x 980x14501800x1000x15401840x1050x17803180x 1600x2000

Note: *-is filter's rating,such as 03 is 3 microns.

**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid

***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.

***-explosion-proof type: add F before type, Omission: normal type


Product features

Heavy Duty Vertical Stainless Steel Coalescing Tank w/Cover

Air Diaphragm Pumps

Air Filter Regulator Assemblies & Needle Valves

CPVC Cleanable Coalesing Media

C-1000 Filter Housing

Bag Filter Housing

Strainer

Oil gate weir for tramp oil removal

4" wheels (2 Rigid and 2 Swivel)

5' discharge hose, gravity flow back to sump


Product applications

Filtering tramp oil, rapeseed oil, sunflower seed oil, canola oil, vegetable oil, vegetable seed oil,coconut oil,used cooking oil,dirty vegetable oil , groundnut oil, olive oil,palm oil,biodiesel oil production pretreatment etc.
