Tramp oil coalescer-separator
Remove tramp oil from soluble, semi-synthetic, and synthetic machine tool coolants to extend fluid life and improve part quality.
Our tramp oil coalescer-separators keep your fluid reservoir free of tramp oil and improve your bottom-line by reducing fluid disposal costs, minimizing downtime, and improving overall productivity.
Tramp oil is responsible for microbial growth that can lead to skin irritations or dermatitis and causes the rotten-egg smell associated with stagnant coolants.
Furthermore, tramp oil can interfere with fluid chemistry to reduce lubricity and cooling rates—resulting in increased tool wear and diminished part quality.
Dirty fluids and bad smells are not good for your operation.
Chips and other particulates can contaminate your machinery’s water-based fluids, while tramp oil can form in your reservoirs.
Particulates and tramp oil can also adversely affect cooling rates and operating temperatures, which can increase friction, reduce output or damage machine parts.
Our filtration designs, develops, and delivers high-quality, low-maintenance tramp oil coalescer-separators that keep your equipment operating efficiently and effectively at the highest level.
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features
Powder-coated steel tank
Air regulator controls air pressure
Needle valve controls fluid flow
Inlet tee-strainer
5-inch HD wheels
Stainless steel tank
High temperature coalescing media
Pre-filtration bag filter
Post-filtration depth filter
Standard Temperature Coalescer
140°F (60°C)
High-Temperature Coalescer Option
180°F (82°C)
Extend life of soluble, synthetic and semi-synthetic coolants
Significantly reduce fluid disposal costs
Greatly minimize downtime for repairs and maintenance
Vastly improve productivity and profitability
Reduce abrasive wear and tear on tools
PRC craftsmanship, expertise & equipment
Filtration coalescer-separators effectively and efficiently removes both large chips, grindings, and small particulates, allowing you to achieve the cleanliness you require.
Product applications
Mainly used for mechanical oil, hydraulic oil, oils such as compressor regeneration lubricating oil , refrigeration oil, heat treatment oil, diesel oil, gear oil, gasoline oil, etc.
