Weaving Oil Coalescing Vacuum Filtration Purification Equipment
Weaving oil coalescing vacuum filtration and purification equipment can quickly remove harmful components in the oil such as moisture, gas and impurities in the lubricating oil, improve the lubricating performance of the oil, and reduce the use of the oil due to excessive moisture or impurity content. Corrosion or corrosion of oil equipment, prolong the service life of oil equipment.
The weaving oil coalescing vacuum filtration and purification equipment purifies and regenerates various mechanical lubricating oils that have been polluted after use, that is, removes water-soluble, gas, mechanical impurities, acid and alkali and other harmful substances in the oil, and ensures the treatment. The finished oil can improve its cleanliness, and make the kinematic viscosity, flash point, etc. meet the national standards for oil products.
Weaving oil coalescing vacuum filtration and purification equipment, the hydraulic lubricating oil treated by the mechanical vacuum oil filter has low emulsification value, very little water content, and high impurity accuracy. It can be reused in high-precision and hydraulic lubrication equipment at home and abroad.
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features:
1) Coalescence separation and vacuum dehydration are combined. The water separation device adopts the world's advanced coalescence separation technology, which can quickly and efficiently separate a large amount of water and micro water from lubricating oil with high water content.
2) Strong ability to filter impurities, large-area, deep-level, high-precision FH rectangular filter system can effectively remove iron filings, dust and impurities in the oil.
3) Tongrui technology of H, P, M polymer adsorption materials. Using high-quality original parts and connection sealing materials, it meets the requirements of high temperature for filtering high-viscosity lubricating oil, and expands the oil filter.
Type and range of purifying oils.
4) The heating adopts optimized pipeline design to ensure uniform heating, no dead oil area and stable oil temperature.
5) Humanized design, dual infrared liquid level control system, electrical automatic protection control system with phase sequence protection, overload protection, overvoltage protection and constant temperature automatic control system ensure the easy, safe and reliable operation.
Product applications:
Widely used in electric power, metallurgy, mining, machinery, chemical industry, transportation, manufacturing, food and other industries , Weaving oil, quenching oil, gear oil, heat treatment oil, anti-wear hydraulic oil, oil with particularly serious emulsification, oil with too much moisture and other corporate waste oil, dirty oil, injection molding oil, cylinder oil, textile oil, high-speed machinery Regeneration, filtration and purification of high-precision lubricating oil such as oil.
