Product Details
Machine oil coalescing dehydration purifier
Our machine oil coalescing dehydration purifier is used in machinery, metallurgy, mining, petroleum, chemical industry, electric power, railway and other fields to purify various oil products. It can quickly get rid of harmful components such as moisture, impurities and volatiles (and other gases) in the oil, improve the quality of the oil and restore its performance. The machine can run online or preheat the oil tank to separately process the oil to meet the various processing requirements of the user for the oil.
Main material: high carbon steel, can be made of 304 stainless steel, customizable.
Working principle: Coalescing and demulsification, vacuum separation, dehydration and degassing, step-by-step precision filtration to remove acid and impurities
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features
1.Strong ability to filter the impurity,strong capability of breaking emulsification. We adopt the high quality filter materials, which has a good function in anti-corrosive, thermos table, mechanical strength. Especially, the precision of eliminates impurity is high and the service life is long. Also, it has a large volume for storing the impurities.
2.The combination of coalescing separation and vacuum dewatering
3.Advanced dielectric condensation device
4.With H.P.M high polymeric absorbing material
5.Using the 3D Stereo-Evaporation technology, which can separate the odor and gas from the oil quickly .
6.This machine installs the new pressure protector, which can control the temperature automatically; also it can drain water on line by the water–separator device. So it is easy to control this machine.
Product applications
Mainly used for mechanical oil, hydraulic oil, oils such as compressor regeneration lubricating oil , refrigeration oil, heat treatment oil, diesel oil, gear oil, gasoline oil, etc.
