Anti-wear hydraulic oil vacuum oil purifier
The anti-wear hydraulic oil vacuum oil purifier is a special equipment for hydraulic oil, lubricating oil and cooling oil that needs to remove a large amount of water and precise impurities. During the operation of machinery manufacturing equipment, water, dust and impurities will be mixed into the hydraulic oil, which will accelerate the oxidation of the oil, and help to generate foam, fouling and sludge formation, causing serious emulsification of the oil, making it difficult to separate oil and water, reducing oil production. Lubrication, speed regulation, heat dissipation and cooling performance. At the same time, it will cause corrosion of metal parts in the equipment, affecting the safe operation of the equipment. There are three forms of existence of water in hydraulic oil: water-in-oil, oil-in-water and dissolved water. The small water droplets pass through the demulsification filter element in the demulsifier and then capillary condensation occurs, and the small water droplets become large water droplets and are separated from the oil, while the large water droplets are continuously accumulated at the bottom of the demulsifier by the action of gravity, discharged through the drain valve, and dissolved. The water is continuously evaporated by heating in a vacuum state, and is removed by a vacuum pump. After removing water, the oil goes through a fine filter to remove mechanical impurities, so as to achieve the purpose of comprehensively purifying the oil.
The oil is sucked into the heater by the vacuum negative pressure through the coarse filter, heated and sucked into the vacuum degassing tank for oil-water (gas) separation. Part of the water in the oil is discharged in the form of water vapor by the vacuum pump, and the oil is transported by the oil pump to the demulsifier for demulsification for re-separation of oil and water, and finally the purified oil is output through the fine filter.
Product parameters
Model
|
AOP-1V-25
|
AOP-1V-32
|
AOP-1V-50
|
AOP-1V-100
|
AOP-1V-150
|
AOP-1V-200
|
Flow rate(L/min)
|
25
|
32
|
50
|
100
|
150
|
200
|
Working pressure(Mpa)
|
|
|
0.6
|
|
|
|
Rated vacuum(Mpa)
|
|
|
≤ - 0.095
|
|
|
|
Water content
|
|
|
5 - 30
|
|
|
|
Air content
|
|
|
≤0.2% |
|
|
|
Coarse filtration(μm)
|
|
|
100 |
|
|
|
Grade 1 filter rating(μm)
|
|
|
10、20 |
|
|
|
Grade 2 filter rating(μm)
|
|
|
3/5 |
|
|
|
Pressure differentials
|
|
|
00.2Mpa |
|
|
|
Voltage(V)
|
|
|
AC 380V(Three-phase)、50Hz |
|
|
|
Motor power(kw)
|
18 |
26 |
36 |
65 |
65 |
135 |
Weight(kg)
|
360
|
470
|
680
|
840
|
960
|
1500
|
Dimensions(mm) |
12500x920x1600
|
1350x980x1600
|
1500x1060x1800
|
1600x1080x2100
|
1800x1200x2200
|
2000x1200x2200
|
Note: * -is filter's rating,such as 03 is 3 microns.
**-is the suitable medium, Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate
hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
****-explosion-proof type: add F before type, Omission: normal type
Product features
The atomization separation technology maximizes the travel of the oil in the vacuum system; the moisture and gas in the oil get enough gasification time; it can fully remove the moisture and gas.
The gas drying and decompression technology doubles the dehydration efficiency.
High-precision filter element, with perfect filter element structure and stable filtration accuracy, the accuracy is 1-3μm. The β value of the oil at the outlet of the filter is greater than or equal to 1000. Combined with gas recoil technology, the service life of the filter element is doubled.
The heater adopts a low-load design to ensure that the oil can be heated evenly in the heater to avoid the cracking and aging of the oil.
Constant temperature heating mode, the temperature can be adjusted freely in the range of 0-100°C, and the heaters are controlled in multiple groups.
The heating system adopts safety interlock protection control to prevent the heater from drying out.
Automatic liquid level control technology realizes man-machine separation.
Introduce vacuum defoaming technology to avoid oil running.
The key electrical components are imported from Europe and the United States, which are safe and reliable.
Phase sequence automatic control technology to prevent line phase loss or phase sequence error from damaging the main components of the equipment.
The oil pump adopts the principle of speed reduction and pressure reduction to reduce noise.
The ship-type chassis structure is adopted to ensure oil-free operation on the ground and reduce environmental pollution.
Product applications
Our anti-wear hydraulic oil vacuum oil purifier is widely used in metallurgy, machinery, mining, transportation, manufacturing and other industries to purify hydraulic oil, refrigeration oil, hydraulic transmission oil, gear oil, vacuum pump oil, internal combustion engine oil, etc . It can quickly remove moisture, demulsification, gas and mechanical impurities in oil, and restore the performance of lubricating oil.
It specially filters water, solid particles, gas and other impurities in industrial lubricating oil, which can quickly restore the performance of waste hydraulic oil and waste lubricating oil, and prolong the service life for more than 3 years.
