Model Number: HYDRApro-407

Permeate Flow : 6,500 gpd (24.6 m 3 /d)

Salt Rejection : 99.7% (99.5% minimum)

Membrane Polymer : Composite Polyamide

Membrane Active Area : 290 ft2 (37.1m 2 )

Feed Spacer : 46 mil (1.17 mm)

Get Quotation

Product Details

HYDRApro-407 is an ultrafiltration technology using PVDF hollow fiber. Pressurized hollow fiber modules are suitable for a wide range of applications, either as final treatment or as pretreatment for reverse osmosis (RO) and nanofiltration (NF).

Application Data

Maximum Applied Pressure: 1200 psig (8.27 MPa)

Maximum Chlorine Concentration: < 0.1 PPM

Maximum Operating Temperature: 113 °F (45°C)

pH Range, Continuous (Cleaning): 2-11 (1-13)

Maximum Feedwater Turbidity: 1.0 NTU

Maximum Feedwater SDI (15 mins): 5.0

Maximum Feed Flow: 75 GPM (17.0 m3/h)

Minimum Ratio of Concentrate to Permeate Flow for any Element: 5:1

Maximum Pressure Drop for Each Element: 10 psi
