Product Details
The substitute ARGO series is installed in the oil circuit of the hydraulic system to remove the metal powder and other mechanical impurities worn by various components in the hydraulic system to keep the oil circuit clean, which can extend the service life of the hydraulic system; The low pressure series filter element is also equipped with a bypass valve. When the hydraulic oil filter element is not replaced in time, the bypass valve can automatically open to ensure the normal operation of the system.
REPLACEMENT Argo hydraulic oil filter p2.0923-01 Test standard:
Our filter elements are tested according to ISO 2943
Compatible with hydraulic oil ISO 3968
Flow characteristics ISO/DIS 3724
Flow fatigue characteristics ISO/DIS 4572
Filter performance test (multi pass test) ISO 2942
Certification of integrity and quality (bubble point test) ISO 3723
Verification of end cap stress ISO 2941
Collapse/burst pressure verification
Product features
1. Quality and performance can be guaranteed as original elements.
2. Temperature range - 4 ° F~212 ° F
3. Seal: nitrile seal, fluorocarbon seal for corrosive fluid.
4. Collapse pressure grade: 21bar-210bar (hydraulic fluid filtration)
5. Filtering precision: 3, 5, 10, 20 and 50 microns.
6. Filter medium: glass fiber, filter paper, stainless steel sintered fiber and stainless steel wire mesh.
7. Fluids are compatible with all petroleum oils, water glycol, oil/water lotion, high water base fluids, and synthetic fluids compatible with fluororubber or EPR seals.
Product parameters
| Model: | P2.0923-01 |
| Place of Origin: | Henan, China |
| Brand Name: | LVDA |
| Life span: | 6000- 8000h |
| Certificate: | ISO9001 |
| Quality: | 100% Tested |
| Working pressure: | -21~210 bar |
| Type: | Hydraulic Filter |
| Material: | Fiber |
| Structure: | Hydraulic Filter |
| Filtration Grade: | Hepa Filter |
| Application: | Liquid |
| Pattern: | Dry |
| Micron Rating: | 10 |
| Direction of Flow: | OUTSIDE->IN |
| Recommended Changeout Differential Pressure: | 20 PSID |
| Outer Diameter, Top: | 3.28 IN (83.31 MM) |
| Inner Diameter, Top: | 1.97 IN (50.04 MM) |
| Length: | 8.94 IN (227.08 MM) |
| Type of Endcap: | PLATED STEEL |
| Type of Media: | PAPER |
| Configuration: | SINGLE OPEN END |
| Carton Weight: | 10.90 LB (4.94 KG) |
Product application
1.Automotive
2.Heavy-duty on-highway transportation
3.Commercial trucks and buses
4.Agriculture
5.Construction
6.Industrial
7.Marine
8.Mining
9.Oil & Gas
10.Power Generation
