Product Details
With a 60-inch length and a 100-micron removal rating, this Vector high flow series cartridge is suitable for coarse large volume particle filtration in the oil & gas, chemical, pulp & paper, and paint industry. It features a polypropylene felt media that serves up to 2x service life.
The Vector High Flow filter cartridge utilizes Pall’s unique “Laid-Over-Pleat” or Ultipleat technology with felt media to extend on-stream service life to your process applications. Vector High Flow elements are available in 20, 40, 60, and 80 inch lengths with media and hardware configurations that allow for broad temperature and chemical compatibility. Additionally, Vector High Flow elements offer the opportunity to employ Pall’s Ultipleat technology and system solution resources in coarse high flow applications.
Product features
1.Big filtration area, high flow rate
2.A variety of precision and length optional
3.Coreless large diameter cartridge
4.Available in both polypropylene and polyester felt media
5.High flow rate per filter cartridge
6.Up to 2x service life vs. comparable coarse large-volume filter elements
7.Available in a variety of filter lengths and grades
8.Features proprietary unique crescent-shaped pleat geometry
9.Inside-to-outside flow pattern that traps contaminants inside the element thus preventing polluting the treated process liquid or gas during cartridge change-out
10.Handle for easy cartridge replacement
Product parameters
Model: | HFV660PP100PH13 |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | ISO9001 |
Quality: | 100% Tested |
Working temperature: | -10~+100℃ |
Working pressure: | -21~210 bar |
Removal Rating | 100 µm |
Media Material | Polypropylene, |
Length | 60 inches |
Hardware Material | White polypropylene |
Outside Diameter (Imperial) | 6 in |
Outside Diameter (Metric) | 152 mm |
Cartridge Length (Imperial) | 60 inches |
Cartridge Length (Metric) | 1524 mm |
Product application
1.Metallurgy:
2. Petrochemical
3. Textiles, electronics and pharmaceuticals
4. Power Plant
5. Steel mills
6. Subway engineering
7. Chemical plant
8. Ships
9.Filtration of process water, condensate water, cooling water, waste water, etc
10.Chemical/chemical industry: Filtration of acid, alkali, solvent, quench water, brine, etc
