Product Details
Harmsco HCP filters offer longer run times with fewer change outs for increased contaminant removal and are easy to change when required. End cap, center tube, and media are thermally bonded as one integral component for added strength.
Fewer cartridges for fewer change-outs and lower maintenance cost
Pleated Polyester-Plus filter media provides higher flow rates and lower initial pressure drop
Pleated surface area provides higher loading capacity for longer filter life and increased particle removal
End cap, center tube and media are thermally bonded as one integral component for added strength
Offered in three sizes (40, 90 and 170) and eight micron ratings (0.35, 1, 5, 10, 20, 50, 100 and 150) to meet all your high flow requirements
Product features
1.High flow capability
2.Lower overall operating cost
3.Reduced waste disposal Longer filter runs for fewer change-outs
4.Increased contaminant removal
5.Operator friendly
6.High flow rates and low pressure drop
7.Pleated surface area provides higher loading capacity for longer filter life and increased particle removal
8.End cap, center tube and media are thermally bonded as one integral component for added strength
9.NSF Certified
Product parameters
Part: | HC/170-5 |
Diameter: | 7-3/4" x 30-/4" |
Material Type: | Polyester-Plus |
Nominal Micron Rating: | 5 |
Maximum Flow Rate: | 150 (GPM) gallons per minute |
Recommended Flow Rate: | 105 (GPM) |
Filtration Area: | 170 Sq Ft |
Max Temperature: | 140 °F (60 °C) |
Box Quantity: | 1 PCs (9"x 9" x 32") |
Filter Media | nominal pleated Polyester-Plus™ |
Center Tubes | ABS or PVC |
End Caps | Pliable PVC with sealing surface built-in |
Model | Micron | Media (sq ft) | Flow Rate (GPM) | Max Flow Rate (GPM) |
HC-170-0.35 | 0.35 | 170 | 105 | 150 |
HC-170-1 | 1 | 170 | 105 | 150 |
HC-170-5 | 5 | 170 | 105 | 150 |
HC-170-10 | 10 | 170 | 105 | 150 |
HC-170-20 | 20 | 170 | 105 | 150 |
HC-170-50 | 50 | 170 | 105 | 150 |
HC-170-100 | 100 | 170 | 105 | 150 |
HC-170-150 | 150 | 170 | 105 | 150 |
Product application
1．Reverse Osmosis Pre-filtration
2．Desalination Pre-filtration
3．Cooling Tower Filtration
4．Chill Water Loop Filtration
5．Food & Beverage Filtration
6．Marine / Aquatic Filtration
7．Coolants
8．Bottled water
9． Organic solvents
10．Municipal Drinking Water Filtration
11．Commercial/Residential Drinking Water Filtration
12．Industrial Water Filtration
13．Industrial Coolant Filtration
