Replacement Hankison precision air compressor  air filter element E7-36 cartridge(E5-36 E9-36)
Replacement Hankison precision air compressor  air filter element E7-36 cartridge(E5-36 E9-36)
Replacement Hankison precision air compressor  air filter element E7-36 cartridge(E5-36 E9-36)
Replacement Hankison precision air compressor  air filter element E7-36 cartridge(E5-36 E9-36)
Replacement Hankison precision air compressor  air filter element E7-36 cartridge(E5-36 E9-36)

Replacement Hankison precision air compressor  air filter element E7-36 cartridge(E5-36 E9-36)

Replacement for Hankison Filter

Model Number: E7-36

Filter Precision: : 1 μm

Type: : in line filter cartridge

Material: : Glassfiber, Stainless steel, Filter paper

Life span: : 6000- 8000h

Certificate: : ISO9001:2015

Get Quotation

Product Details

AIRFILTER

The air filter is an important part of the air intake system of the air compressor, which consists of an assembly of several air filter elements

FUNCTION

Its main function is to filter out the harmful impurity particles that will enter the air compressor screw,ensure sufficient and clean air to enter the air compressor, reduce the wear of the air compressor screw, bearing, cylinder liner,etc, and prolong the service life of the equipment.

The filtration efficiency is high, which can effectively ensure the reliable operation of the air compressor; The intake resistance is low, the intake resistance is small,so that sufficient air can be supplied.The ash storage capacity is strong, reduces the maintenance times of the air filter, and reduces the cost of use.

LVDA precision filter using multi-layer filter materials(includes borosilicate fibrous layer,glass fiber layer,activated carbon fiber layer,multi-layer stainless steel mesh layer),which can help achieve high quality air without oil and impurities.


Grade 7: Air Line. Provides removal of liquid water and oil. Removes solid particulate to 1.0 micron with a 1.0 ppm w/w maximum remaining oil content (established in accordance with CAGI standard ADF400 and is based on 100°F inlet temperature). The first stage of filtration captures larger particles with alternating layers of fiber media and screen. The second stage of filtration coalesces aerosols and captures solid particles with multiple layers of epoxy bonded, blended fiber media.


Product features

1. High porosity, good air permeability, low resistance and low pressure difference;

2. After forming into a folded shape, the filtering area is large and the dirt holding capacity is large;

3.Thickened material, high-precision sponge, high temperature resistance, corrosion resistance, suitable for high viscous liquid filtration, long service life;

4. Good regeneration performance, can be used repeatedly after chemical cleaning, high temperature and ultrasonic cleaning;

5. All stainless steel structure, wide chemical compatibility;

6. Built-in high-quality sealing ring, good sealing performance;

7. Industrial casting strictly controls the production details to control the error and control the error within an acceptable range.


Product parameters


Model:

 E7-36

Place  of Origin:

Henan,  China

Brand  Name:

LVDA

Type:

in  line filter cartridge

Material:

Glassfiber,  Stainless steel, Filter paper

Filter  Precision:

1 μm

Life  span:

6000-  8000h

Certificate:

ISO9001:2015

Style:

Activated  carbon filter

Efficiency:

99.99%

Dimension(L*W*H):

10*10*50cm

Weight:

0.8kg



Hankison  New Style Series

  Model Class FLOW Rate

E1

E3

E5

E7

E9

Filter  Precision (μm)

 Residual Oil Component (ppm)

NM3/min

Degreasing  deodorant filter element

Super  UF Degreasing Filter Element

UF  Degreasing Filter Element

Ventilation  Pipe Filter Element

Separate  Filter Element

0.57

E1-12

E3-12

E5-12

E7-12

E9-12

E1:0.01

0.001

1

E1-16

E3-16

E5-16

E7-16

E9-16

E3:0.01

0.001

1.72

E1-20

E3-20

E5-20

E7-20

E9-20

E5:0.01

0.01

2.9

E1-24

E3-24

E5-24

E7-24

E9-24

E7:1

1

4.9

E1-28

E3-28

E5-28

E7-28

E9-28

E9:3

5

7.2

E1-32

E3-32

E5-32

E7-32

E9-32


11

E1-36

E3-36

E5-36

E7-36

E9-36


14

E1-40

E3-40

E5-40

E7-40

E9-40


18

E1-44

E3-44

E5-44

E7-44

E9-44


22

E1-48

E3-48

E5-48

E7-48

E9-48



Product application

1. Metallurgy: It is used for the filtration of the hydraulic system of rolling mills and continuous casting machines and the filtration of various lubricating equipment.

2. Petrochemical: used for separation and recovery of finished products and intermediate products in the process of oil refining and chemical production, liquid purification, purification of magnetic tapes, optical discs and photographic films in manufacturing, oil field well injection water and natural gas for particle removal and filtration.

3. Textiles, electronics and pharmaceuticals

4. Power Plant

5. Steel mills

6. Subway engineering

7. Chemical plant

8. Ships

9. Paper mill
