Product Details
As a component of the internal combustion engine, It plays a very important role in the lubrication system. During the combustion of process, it can filter out metal debris mixed with oil, toner and oil gradually produce gum and other impurities, These impurities will accelerate the wear of moving parts, and could easily lead to the clogging of the lubricating oil passage. oil filter ensures the normal operation of internal combustion engine, the service life of the engine has been greatly improved and can prolong the service life of other parts.
The oil filter is to filter out the metal abrasives and dust generated during the engine work, and the lubricant filtering device of impurities such as oxidized carbon and rubber precipitated, water at high temperature.
Using high-quality oil filter can reduce the engine of the engine, reduce the wear of the machine, and extend the service life.
According to the connection method with the mainstream channel, the oil filter can be divided into a full stream oil filter and a diversified oil filter.
The full stream oil filter is connected in series with the mainstream road. All or most of the lubricant is filtered by the filter during the engine work.
The diversion oil filter is connected to the mainstream channel. The engine is only about 10%of the lubricating oil during working.
In addition, Fleet guard also provides high -performance composite filters with unique setting and diversion functions in one. It is used in series with the mainstream lane, which is convenient and cost -effective.
LF9070 Cross Reference:
Cummins 2882673
Baldwin BD7153
Case IHC 324617A1, 441700A1
Fleetrite LFR89000
Fram PH8690
John Deere PMLF9000
Kralinator D390
Luberfiner LFP9007
Manitowoc A047950
Napa 7745XD
Purolator Facet L65328
Wix 57745
Product features
Manufacturer
Competitive price can be offered
Optimum paper folding
Large dust holding capacity
Good temperature resistance
Good anti-humidity performance
No distortion of pleats
Environmental Friendly
OEM & ODM Customized is accepted
On-time delivery
Durable and reliable
Ecnomical,practical,and easy to install
Product parameters
Part Number | LF9070 |
Parts Name | Oil Filter |
Brand | Fleetguard |
Overall Height | 352.50 mm |
Largest OD | 118.11 mm |
Gasket OD | 118.87 mm |
Gasket ID | 101.60 mm |
Thread Size | M95 X 2.5-7H INT |
Type: | Oil Filter |
Material: | Paper Core |
Structure: | Filter Element/Assy |
Filtration Grade: | Hepa Filter |
Application: | Liquid |
Pattern: | Wet |
Guarantee: | 5000kms |
Application: | Auto Engine/Industrial Machinery |
Descriptions: | 1.For removal dust and other particles |
2.Adopt high performance 100% wood pulp filter paper |
3.100% soft thick liquid paper and 100% non-woven. |
4.Filtration efficiency over 99.2% |
5.High standards from first grade materials specific to its application for
American, European, Australia, Southeast Asia,India, Mid-East and African market. |
Product application
1. Construction machinery industry: excavator, loader, roller, rotary drilling rig, paver
2. Power industry: generator sets, mobile power stations
3. Petrochemical industry: fuel dispensers, oil tankers, mobile fuel tankers
4. Mechanical processing equipment: various mechanical hydraulic system filters such as machining center, lathe, milling machine, bending machine, etc
5. Agricultural machinery: harvester, tractor, lawn mower
6. Transport vehicles: heavy trucks, mixer trucks, buses, sprinklers
7. Ships
