Product Details
Function of oil filter: filter impurities
Generally, all parts in the engine work normally by lubricating the engine oil, but the metal chips, dust, carbon deposits oxidized under high temperature and some water vapor generated during the operation of the parts will continue to mix with the engine oil. After a long time, the normal service life of the engine oil will be reduced, which may affect the normal operation of the engine in serious cases.
Therefore, the role of the oil filter is reflected at this time. To put it simply, the function of the oil filter is to filter most impurities in the oil, keep the oil clean and extend its normal service life. In addition, the oil filter should also have strong filtering capacity, small flow resistance, long service life and other properties.
Oil filter composition: housing filter element
In brief, the oil filter is mainly composed of filter paper and housing. Of course, there are also auxiliary parts such as sealing ring, support spring, bypass valve, etc. These auxiliary parts also play an important role. For example, the role of the bypass valve is that when the filter paper fails due to excessive impurities, the oil will flow into the engine through the bypass valve for lubrication. However, only from the appearance, we can see the oil filter as a whole, but not the filter paper, bypass valve and other parts.
Product features
1. Longer service life: Regular use of LVDA spare parts to maintain your equipment can ensure that your device has a longer service life. We guarantee that each new component has the same good performance as the replaced component.
2. High quality: our original parts are manufactured according to the same strict standards as the compressor you have installed. These parts have passed the durability test and proved to be a better guarantee for your investment.
3. Reliability and productivity: The use of original parts can fundamentally reduce the risk of production stoppage, because production stoppage is not only costly, but also may affect product quality, delivery time and profit margin. In short, original parts enable your compressed air unit to perform better.
4. Energy saving and cost-effectiveness: regular replacement and use of LVDA parts will enable your compressed air device to have a longer service life and achieve a smaller average pressure drop, so as to achieve energy conservation, achieve cost-effectiveness and provide a larger exhaust volume at a lower cost of ownership.
Product parameters
Overall Height | 142.1 mm (5.594 in) |
Largest OD | 93.5 mm (3.681 in) |
Seam OD | 93.5 mm (3.681 in) |
Gasket OD | 70 mm (2.756 in) |
GASKET INSIDE DIAMETER | 62 mm (2.441 in) |
Thread Size | 3/4-14 BSP |
Standpipe | NO |
TWA MICRON @ BETA=2 | 12 micron (12 micron) |
TWA MICRON @ BETA=20 | 22 micron (22 micron) |
TWA MICRON @ BETA=75 | 30 micron (30 micron) |
Notes | Spin-On |
Product application
1. Metallurgy: It is used for filtering the hydraulic system of steel rolling mill and continuous casting machine and filtering various lubricating equipment.
2. Petrochemical: separation and recovery of products and intermediate products in oil refining and chemical production, particle removal and filtration of oilfield well water and natural gas.
3. Textile: purification and uniform filtration of polyester melt during wire drawing, protective filtration of air compressor, oil and water removal of compressed gas.
4. Electronics and pharmacy: pretreatment filtration of reverse osmosis water and deionized water, pretreatment filtration of cleaning solution and glucose.
5. Thermal power and nuclear power: purification of lubricating system, speed control system and bypass control system oil of gas turbine and boiler, and purification of feed pump, fan and dust removal system.
6. Mechanical processing equipment: lubrication system and compressed air purification of paper machinery, mining machinery, injection molding machines and large precision machinery, and dust recovery and filtration of tobacco processing equipment and spraying equipment.
7. Railway internal combustion engine and generator: filtering of lubricating oil and engine oil.
8. Automobile engine and construction machinery: air filter, engine oil filter, fuel filter for internal combustion engine, various hydraulic oil filters, diesel oil filters and water filters for construction machinery, ships and trucks.
9. Various lifting and handling operations: hoisting, loading and other engineering machinery to fire fighting, maintenance, handling and other special vehicles, ship's cargo winch, windlass, blast furnace, steelmaking equipment, ship lock, ship door hoist, theater's lifting orchestra and lifting stage, various automatic conveyor lines, etc.
