Product Details
Our oil purification and decoloration machine can quickly remove out impurities, water, gases and recover the oil color to original color. This machine uses our special additive to discolor, which is purely natural and has high efficiency. It can treat hydraulic oil, machinery oil, coolant oil, cooking oil, coconut oil in oil field, mine, metallurgy, electricity, transportation, manufacturing, food industry. The treated oil is very clear and transparent. It can also be equipped with waste oil distillation plant to highly improve the dark color of base oil/diesel after distillation process.
And it is asked by customer to pre-treat the used cooking oil before further biodiesel.
This machine adopts the the latest micro-filtration technology,which is a multi-functional purification system with vacuum oil filter, fine filter and decoloring device.It uses pure physical treatment to remove water, gases, impurities and decolor,which will not affect the composition and performance of the oil. Equipped with chain protection device, the machine is easy to operate, safe and reliable.
This machine can also be wrapped with a heat preservation layer for some special conditions like treating oils which are easy to solidify.
Cleanlinesss6(NAS1638)
We also have other types of oil purifier and testers available for our customers.
Main Products
Oil Purifier:
Single-Stage Vacuum Transformer Oil Purifier
Double High Vacuum Transformer Oil Purifier
Multiply-Function insulating oil treatment machine
Turbine Oil Purification Apparatus
Lubricating oil/ hydraulic oil purification unit
Portable light Fuel oil purification machine
Vacuum dehydrator
Phosphate ester fire-resistance oil purifier
Plate pressure oil purifier
Vacuum dehydrator
Explosion protection filtration machine
Press filtration system
Vacuum pumping device
Cooking oil purification machine
Centrifugal oil purification machine
Portable oil filtering and oiling machine
Product parameters
| Technical item |
Unit |
|
|
|
Model |
|
|
|
|
|
AD-30 |
AD-50 |
AD-100 |
AD-150 |
AD-200 |
AD-250 |
AD-300 |
| Flow |
L/min |
30 |
50 |
100 |
150 |
200 |
250 |
300 |
| Average power |
Kw/h |
7 |
7 |
9 |
9 |
12 |
15 |
15 |
| Heating power |
Kw/h |
3 |
4.5 |
6 |
6 |
9 |
9 |
11 |
| Working vacuum |
Mpa |
|
|
|
-0.04～-0.098 |
|
|
|
| Working oil temperature |
℃ |
|
|
|
30～160 |
|
|
|
| Working pressure |
MPa |
|
|
|
≤0.8 |
|
|
|
| With power supply |
V |
|
|
|
380 |
|
|
|
| Noise |
db(A) |
|
|
|
≤70 |
|
|
|
Features
Fast decolorization, obvious effect, pure physical oil purification method, high degree of automation, simple and convenient operation, and movable. It can effectively remove pollutants in oil products, degas, dehydrate, remove mechanical impurities and severely oxidized sludge, asphaltenes, carbon residues, colloids, chromatin, etc.;
The various properties and physical and chemical indicators meet the relevant oil standards, and improve the cleanliness, flash point and emulsification performance of the oil.
Applications
Electric power, petroleum, chemical industry, metallurgy, mining, machinery, aviation, shipbuilding, railway and many other industries.
It is mainly used for the centralized regeneration of various red and blackened dirty oils and scrapped oils. Oils such as Hydraulic Oil,Turbine Oil,Lubrication Oil,Gear Oil,Transformer Oil,Diesel Fuel.
