Engine Oil Purifier

Model Number:

Rated pressure(Mpa) : 0.34

Original pressure loss(Mpa) : ≤0.02

Coarse filtration accuracy(μm) : 40 meshes

Use temperature(°C) : 6~80

Recommended viscosity for use(cSt) : 10~160

Get Quotation

Product Details

Portable & mobile filtration systems

Our portable & mobile filtration systems is a unique design, portable, and lightweight hand-held transfer filtration system, designed for hard to reach places.

The dual element design allows for two stage filtrations for numerous filtration options. With the portable & mobile filtration systems heavy-duty stainless-steel frame, industrial grade motor and pump it is ideal for most hydraulic and lube oil applications.

Parameters

ModelAOP-6-*/**
AOP-10-*/**
AOP-16-*/**

Rated flow(L/min)

6
1016

Rated pressure(Mpa)

 0.34
Original pressure loss(Mpa)≤0.02

Coarse filtration accuracy(μm)

40 meshes

Fine filtration accuracy(μm)

3、 5、 10、 20、 40

Alarm differential pressure(MPa)

0.2MPa

Use temperature(°C)

6~80

Recommended viscosity for use(cSt)

10~160

Power supply(V)

AC380V three-phase, AC220V three-phase

Motor Power(kw)

0.180.250.35

Weight(kw)

131618

Dimensions(mm)

650x680x980
650x680x980
720x680x1020

Note: *- filter precision, such as 003 is 3 microns

**-Filter media, omitted: ordinary hydraulic oil; BH: water glycol; V: phosphate ester hydraulic oil.

Features

Lightweight & Compact

4 GPM Flow Capacity

Two Filters:

Longer Filter Life

Two Stage Filtration

Clean, Easy Filter Change-Out

Filtration down to 3 Micron (Absolute)

Industrial Quality Vane Pump

Heavy-Duty Stainless-Steel Frame

Pump Safety Relief Valve

Strainer on Inlet

Easy to Read Pressure Gauges

Applications

Our portable & mobile filtration systems are commonly found in the following markets:

On / off road diesel transfer applications

Fluid transfer filtering

Water removal treatment

Fluid conditioning
