Coalescence-separation light fuel oil purification unit
Our machine adopts coalescence separation filter which integrates high precision filtration and high efficient demulsification and dehydration into one, and can remove large amount of water without heating. It has the fastest dehydrating speed in domestic. This machine can quickly separate water from oil though the water content reach 50%. The oil cleanness can reach NAS six grade. This machine is used conveniently with go-cart type design. It’s specially suitable for purifying high water content light oil, jet fuel, gasoline, kerosene, diesel, light and low viscosity lubricating oil .
Product parameters
| Model | A0P-D25 | AOP-D50 | A0P-D100 | AOP-D150 | A0P-D200 | AOP-D400 |
| Rated flow(L/min) | 25 | 50 | 100 | 150 | 200 | 400
|
| Rated pressure(MPa) | 0.6 |
| Initial pressure loss (Mpa) | ≤0.1 |
| Filtered water content | ≤100 |
| Coarse filtration( μ m) |
100 |
| Grade 1 filter rating( μ m) | 10、20 |
Grade 2 filter rating( μ m) | 3、5 |
| Pressure differentials | 0.2Mpa |
| Working temperature(°C) | 25- 80 |
| Recommended viscosity(cSt) | 10-120 |
| Voltage(V) | AC 380V(Three-phase)、50Hz |
| Motor power(kw) | 0.75 | 1.1 | 2.2 | 4 | 5.5 | 13
|
| Weight(kg) | 150 | 200 | 300 | 520 | 860 | 2860
|
| Dimensions(mm) | 1200x 800x1250 | 1350 x800x1400 | 1740x 980x1450 | 1800x1000x1540 | 1840x1050x1780 | 3180x 1600x2000 |
Note: *-is filter's rating,such as 03 is 3 microns.
**-is the suitable medium,Omission:General hydraulic oil;BH:Water - glycol , V:Phosphonate hydraulic fluid
***- the medium viscosity is too high or the oil temperature is low,need to add the heating device.
***-explosion-proof type: add F before type, Omission: normal type
Product features
* Using coalescing separation technology to demulsificate, coalesce and separate the free water and the emulsified water.
* It adopts special oil water separator without heating requirement, and its dewatering efficiency is above 20 times of other kinds of purifier.
* As no heating is needed, energy consumption and operating cost is reduced.
* This machine is light and small size.
* Low operation cost, 20%-40% lower than vacuum oil purifier, centrifuge and plate frame pressure filter machine.
Product applications
* State Grid: Oil for converter stations, substations, booster stations, substations, etc.; transformer oil, insulating oil, silicone oil.
* Electric power: turbine oil, hydraulic oil, anti-wear hydraulic oil, gear oil.
* Petroleum and petrochemical: turbine turbine oil, compressor lubricating oil, hydraulic oil 32#, 68#, 100#, 150#, refrigeration oil.
* Wind power generation: variable speed oil gearbox: lubricating oil, hydraulic oil, turbine oil.
* Hydroelectric power generation: turbine lubricating oil and speed regulating oil 46#, anti-wear hydraulic oil, turbine oil.
* Aerospace: aviation hydraulic oil, aviation kerosene.
* Cement: anti-wear hydraulic oil, turbine oil, hydraulic oil, compressor oil.
* Chemical industry: lubricating oil, gear oil, turbine oil, hydraulic oil, compressor oil.
* Compressor: compressor refrigeration oil.
* Automobile manufacturing: engine oil, filtration of experimental platforms, hydraulic oil, and kerosene.
* Steel: hydraulic oil, turbine oil, heat transfer oil.
* Aluminum industry: hydraulic oil, anti-wear wave pressure oil.
