About Compressed Air:
Compressed air is the second-largest power source after electricity, and it has a multi-purpose process gas source. The unfiltered and separated
compressed air contains a considerable amount of water, solid particles, dust, oil mist, bacteria and other pollutants. These pollutants have a certain
impact on the profitability and production costs of the factory. In order to maintain the competitive advantage of the factory, It is necessary to implement
sustainable measures and apply quality-assured purification equipment.
PF
As a primary filter, particles whose diameter more than 5μm can be removed, the maximum residual oil content is negligible.
AO
High efficiency general protection, dust particles, water mist and oil mist whose diameter more than 1μm can be removed, the residual content of oil mist does not exceed 0.6mg/m³(21ºC), 1ppm(w).
AA
High efficiency oil removal filtration, dust particles, water mist and oil mist whose diameter more than 0.01μm can be removed, the residual content of oil mist does not exceed 0.01mg/m³(21ºC), 0.01ppm(w).
AX
Ultra-efficient filtration, dust particles, water mist and oil mist whose diameter more than 0.01μm can be removed, the residual content of oil mist does not exceed 0.001mg/m³(21ºC), 0.001ppm(w).
ACS
Dust particles whose diameter more than 0.01μm, oil vapor and odor can be removed, the maximum residual residual content of oil vapor does not exceed 0.003mg/m³(21ºC), 0.003ppm(w).
AR
Dust particles whose diameter more than 1μm can be removed.
AAR
Dust particles whose diameter more than 0.01μm can be removed.
Product features
1.Environmental Production
2.Favourable Price
3.Stable and constant pressure
4.Long service life
5.High efficiency
6.Durable and reliable
Product parameters
Model: | L030ACS |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | ISO9001:2015 |
Quality: | 100% Tested |
Application: | In-line Compressed Air Filter |
weight: | 1kg |
precision | 0.01-0.1micron |
efficiency | 99% |
Filtration Grade | PF | AO | AA | AX | ACS | AR | AAR |
Size of solid particles(ISO12500-3) | 5μm | 1μm | 0.01μm | 0.01μm | - | 1μm | 0.01μm |
Filtration performance of solid particles(ISO12500-3) | - | 99.999+% | 99.999+% | 99.999+% | 99.999+% | 99.999+% | 99.999+% |
Filtration performance of oil(ISO12500-3) | 50% | 80+% | 99.9+% | 99.99+% | - | - | - |
Residual oil content(ISO12500-1) | 5mg/m³ | 0.6mg/m³ | <0.01mg> | <0.001mg> | <0.004mg> | - | - |
Product application
1．Chemical and petrochemical industry
2．Pharmaceutical industry
3．Breathing air
4．Prefiltration of sterile filters
5．Filling machines
6．Food & beverage industry
7．Packing machines
8．Process industry
