Replacement for Ultra Filter AKP04/20 with high quality(AG 0012)

Replacement for Ultra Filter AKP04/20 with high quality(AG 0012)

Replacement for Ultrafilter Filter

Model Number: AKP04/20

Material(s) : Activated carbon and Borosilicate

Connection : Perbunan Gasket

Working Temperature : 10°C to 40°C

Filter surface : 04/20 Silicon free

Degree of filtration : 0.003 mg/m3

Product Details

Ultrafilter offers filter elements for most compressed air applications. These high quality filter elements are made with the finest pleating technology and aluminum endcaps. Unique to the industry with their extremely low differential pressure. The AK filter elements consist of a two-stage filtration. All particles are kept in a nanofiber depth filter media, while the activated carbon adsorbs all oil vapors and gaseous hydrocarbons. Ultrafilter offers filter elements for most compressed air applications. These high quality filter elements are made with the finest pleating technology and aluminum endcaps. Unique to the industry with their extremely low differential pressure.

Product features

1.High load of activated carbon. High adsorption capacity and long service life

2.Flow distribution at the air inlet Optimized flow distribution and adsorption efficiency

3.Embedded activated carbon No abrasion of grounded activated carbon

4.Depth filter stage of bonder-free woven nanofibres Improved particle retention according to ISO 8573-1 can be achieved

5.2 O-rings Perbunan, silicone-free and free of parting compounds as standard

6.Support sleeves Stainless steel 1.4301/ 304

Product parameters

Model:	AKP04/20
Place of Origin:	Henan, China
Brand Name:	LVDA
Life span:	6000- 8000h
Certificate:	TS16949/ISO9001:2015
Efficiency:	99.99%
Quality:	100% Tested
Material:	Glassfiber, Stainless steel, Filter paper
Max Temp	65 °C
Diameter	52 mm
Length	104 mm

Max Differential pressure	Max. 2 bar (@ 20°C)
End Caps	Aluminium end caps
Filterhouse	AG 0012
Material(s)	Activated carbon and Borosilicate
Connection	Perbunan Gasket
Working Temperature	10°C to 40°C
Degree of filtration	0.003 mg/m3
Filter surface	04/20 Silicon free
Function	Removes oil vapors and odors from compressed air
