I-63885TB Coalescer Cartridge

Product Details

I-63885TB is a high-efficiency Coalescer Cartridge. It is primarily used as a first-stage element in aviation fuel filtration and industrial hydrocarbon processing to remove solid contaminants and separate water from fuel.

Dimensions: 6" Outer Diameter (OD) x 3.5" Inner Diameter (ID) x 38" Length

Micron Rating: 0.5 µm

Base Type: Threaded Base

Maximum Collapse Pressure: 75 PSI

Recommended Change-out Pressure: 15 PSI

Particulate Removal: The filter medium blocks and traps fine solid particles, silt, rust, and scale down to 0.5 microns.

Coalescence: It coalesces (merges) tiny, dispersed water droplets suspended in the fuel into larger drops. These larger drops then settle by gravity to the bottom of the filter vessel.
