Replace Elements Hydraulic Filter 941041Q /941043Q
Replace Elements Hydraulic Filter 941041Q /941043Q
Replace Elements Hydraulic Filter 941041Q /941043Q

Replace Elements Hydraulic Filter 941041Q /941043Q

Replacement for Parker filter

Model Number: 941041Q / 941043Q

Nominal Filter Rating : 2 micron

Max Pressure : 3000 psi (206.9 bar)

Bypass : 50 PSI (3.5 bar)

Operating Temperature : -40F to 225F (-40C to 107C)

Nominal Flow Rating : 30 GPM (114 LPM)

Get Quotation

Product Details

Element Length: Single
Nominal Filter Rating: 2 micron
Efficiency βx(C) ≥ 200: 4 µ
Efficiency βx(C) ≥ 1000: 5 µ
Collapse Pressure (bar): 20.7 bar
Collapse Pressure (psi): 300 psi
Filter Media Type: Ecoglass III
Operating Temperature: -15F to 250F (-26C to 121C)
Seals:Fluorocarbon

Series: WPF5
Element Type: Coreless
Media Composition Detail: Multilayer fiberglass with PBT mesh on both sides
Filter Media Code: 02QE
D Dimension: 3.77 in (95.75 mm)
E Dimension: 17.24 in (438 mm)
Top Endcap Material: Glass reinforced nylon
Bottom Endcap Material: Glass reinforced nylon
Glue Side Seam Adhesive: Polyurethane
Glue Endcaps Adhesive: Polyurethane
Element Weight (kg): 3.52
Division: Hydraulic Filter
