Replacement Elements - PARKER High Pressure Filter WPF Series | #941037Q(60*260)

Replacement Elements - PARKER High Pressure Filter WPF Series | #941037Q(60*260)

Replacement for Parker filter

Model Number: 941037Q

Nominal Filter Rating: : 10 micron

Collapse Pressure (bar): : 20.7 bar

Element Weight (kg): : 1.32

D Dimension: : 2.72 in (69 mm)

E Dimension: : 10.31 in (262 mm)

Product Details

LVDA engineers have developed what soon will be the industry standard in high pressure hydraulic filtration. The 7,000 psi WPF series incorporates many advanced features designed for one reason: to improve your bottom line.

LVDA Pressure Filter (WPF) Series offers an innovative alternative to conventional high pressure and reverse flow filters. The WPF design incorporates all the benefits of Wireglass media along with a unique reverse flow and bypass valve arrangement.

There is no better high pressure filter available today for durability and performance. The reduction of your operating costs is our primary concern, and we are committed to contributing towards your success.

Product features

1. OEM quality standard guaranteed.

2.Product upgrading and expansion of species.

3.Good quality with competitive prices.

4.Flexible and convenient logistic service.

5.Excellent and high-quality control.

6.Long lasting working life time.

Product parameters

Model	941037Q
Place of Origin	Henan, China
Brand Name	LVDA
Life span	4000H
Certificate	ISO9001:2015
Quality	100% Tested
lement Length:	Single
Nominal Filter Rating:	10 micron
Efficiency βx(C) ≥ 200:	9 µ
Efficiency βx(C) ≥ 1000:	12 µ
Collapse Pressure (bar):	20.7 bar
Collapse Pressure (psi):	300 psi
Filter Media Type:	Ecoglass III
Operating Temperature:	-15F to 250F (-26C to 121C)
Seals:	FKM: Fluorocarbon
UOM:	EA
Series:	WPF3
Element Type:	Coreless
Media Composition Detail:	Multilayer fiberglass with PBT mesh on both sides
Filter Media Code:	10QE
D Dimension:	2.72 in (69 mm)
E Dimension:	10.31 in (262 mm)
Top Endcap Material:	Glass reinforced nylon
Bottom Endcap Material:	Glass reinforced nylon
Glue Side Seam Adhesive:	Polyurethane
Glue Endcaps Adhesive:	Polyurethane
Element Weight (kg):	1.32
Parker Division:	Hydraulic Filter
Parker Group:	Filtration
