Product Details
The main advantages of spin-on filters are the easy and quick replacement of the exhausted cartridge and the reduction of maintenance costs. Moreover Spin-on configuration is strategic when the machines involved in the maintenance operate in particularly contaminated contexts and difficult environmental conditions.
Hydraulic filter
80% of hydraulic system component failures are caused by excess contamination in the hydraulic system.
Hydraulic or fluid power systems can be found on a variety of equipment. Systems range from the relatively simple power steering and transmission of trucks and buses, to the more complex systems found in agricultural, construction, marine and mining applications.
Oil filter
Oil is the life-blood of an engine, which means the oil filter should never be taken for granted, especially in harsh heavy-duty environments. The small price maintenance teams must pay for premium filters is well worth the cost.
LVDA oil filters are the most efficient and cost-effective filters in severe conditions. They feature microfiber "glass" media in order to filter out more of the small, engine-destroying particles.
Fuel filter,fuel water separator
Fuel filter is often the forgotten filter. Yet the fuel put into diesel and off-road equipment, more often than not,contains contaminants such as dirt, rust, scale and water. These impurities can plug fuel injectors and carburetors, resulting in engine malfunction or deterioration.
Product features
1.LVDA hydraulic filter element has high porosity, good permeability, small resistance and low differential pressure
2. It has high temperature resistance, corrosion resistance and is suitable for filtering highly viscous liquid.
3. The filtering area is large and the dirt holding capacity is large.
Product parameters
Model: | 1625480000 |
Place of Origin | Henan, China |
Brand Name | LVDA |
Life span | 2000- 4000h |
Certificate | ISO9001:2008 |
Quality | 100% Tested |
Package Dimensions | 8.78 x 4.21 x 4.02 inches; 1.91 pounds |
Material | wood pulp curing paper |
Total Height (H-TOTAL) | 210 mm |
Thread (TH) | M M23 Female Bottom 1.5 |
Product Net Weight (WEIGHT) | 0.95 Kg |
Largest Inner Diameter (Ø IN-MAX) | 15 mm |
Outer Diameter (Ø OUT) | 98 mm |
Product application
1.metallurgy: used for rolling mill hydraulic system of continuous casting machine filter and various kinds of lubrication equipment
2.petrochemical refinery chemical production of the product and the intermediate product in the process of separation and recovery, the well water and gas injection in addition to the particle filter
3.thermal power and nuclear power: lubricating system of steam turbine boiler speed control system of bypass control system for oil purification, purification of feed water pump and fan dust removal system
