Product Details
The filter element is used to protect specific components in the hydraulic system. It is installed upstream of the components to be protected in the medium pressure pipeline to filter solid particles and colloidal substances in the working medium, effectively control the pollution degree of the working medium, and make the components work normally. The hydraulic oil filter element is mainly made of stainless steel woven mesh, sintered mesh, and iron woven mesh. Because the filter materials used are mainly glass fiber filter paper, chemical fiber filter paper, and wood pulp filter paper, it has the characteristics of high concentricity, large pressure bearing, good straightness, stainless steel material, no burrs, and long service life. Its structure is made of single-layer or multi-layer metal mesh and filter materials, In specific use, the number of layers and mesh of the screen are determined according to different use conditions and purposes.
Testing standard:
ISO 2941
Collapse & Burst Resistant
ISO 2942
Fabrication & Integrity Test
ISO 2943
Material Compatibility with Fluids
ISO 3724
Flow Fatigue Characteristics
ISO 3968
Pressure Drop vs. Flow Rate
ISO 16889
Multi-pass Performance Testing
Product features
1. OEM quality standard guaranteed.
2.Product upgrading and expansion of species.
3.Good quality with competitive prices.
4.Flexible and convenient logistic service.
5.Excellent and high-quality control.
6.Long lasting working life time.
Product parameters
Model | CR224C10R |
Place of Origin | Henan, China |
Brand Name | LVDA |
Life span | 2000- 4000h |
Certificate | ISO9001:2008 |
Quality | 100% Tested |
OD Top: | 4.98 |
OD Bottom: | 4.98 |
ID: | 2.568 |
Length: | 9.84 |
End Caps: | Corrosion Resistant Steel / Aluminum |
Center Tube: | Corrosion Resistant Steel |
Media: | Microglass Fiber Media |
Seal: | Buna (Nitrile) |
Bypass Setting: | - |
Collapse Rating: | 150 psid |
Filtration Rating: | Bx = 200 Bx[c] = 1000 |
Hydrafil# : | BF-OMT-633503-L10-10MB |
Product application
1, Hydraulic Engineering Systems Industry;
2, Mining and Metallurgical Equipment Industry;
3, Construction, engineering machinery industry;
4, Machine Tool Industry;
5, Agricultural machinery industry;
6, Plastic machinery industry;
7, Petrochemical industry;
8, Ship and marine engineering equipment industry.
