Product Details
Ensure that the hydraulic oil is not used under high temperature; The oil will quickly deteriorate under high temperature;
The precision filter element is used to filter the hydraulic oil, so that the pollution degree of the oil products can be kept at NAS8 for a long time. The filter element of the equipment is generally of poor precision, which cannot ensure the cleanliness of the hydraulic oil. Because the dirt capacity limit of the hydraulic station is only 5um, and the precision of the filter element of the hydraulic station is usually greater than this size. It is scientifically stipulated that the pollution degree of the general hydraulic station is controlled at NAS level less than 8, and the requirements for equipment with servo mechanism are higher, which should be less than 7, If you have removed the servo valve, you will understand why the hydraulic oil pollution should be controlled so high. It is better to buy a precision oil filter for online filtering. Now some filter elements have reached the accuracy of 0.1um;
Check the oil products regularly. The filter element is a consumable, and it needs to be replaced immediately after it is blocked. Pay attention to flushing the oil tank and pipeline of the system. When refueling, use the refueling device with a filter to prevent the oil in the tank from directly contacting the air. Do not mix the old and new oil. It is helpful to extend the service life of the filter element.
Product features
1.LVDA hydraulic filter element has high porosity, good permeability, small resistance and low differential pressure
2. It has high temperature resistance, corrosion resistance and is suitable for filtering highly viscous liquid.
3. After the filter element is folded, the filtering area is large and the dirt holding capacity is large.
Product parameters
Model: | 3693550 |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 2000- 4000h |
Certificate: | ISO9001:2015 |
Quality: | 100% Tested |
OD Top: | 3.605 |
OD Bottom: | 3.605 |
ID: | 1.9 |
Length: | 6.36 |
End Caps: | Corrosion Resistant carbon Steel,galvanized |
Center Tube: | Corrosion Resistant carbon Steel |
Media: | Pending |
Collapse Rating: | 3000 psid |
Filtration Rating: | Bx = 200 Bx[c] = 1000 |
Hydrafil# : | BF-HUS-495014-L7-12MV-PC |
Precision | 10 micron glass fiber |
Product application
1.Metallurgy
2. Petrochemical
3. Textiles, electronics and pharmaceuticals
4. Power Plant
5. Steel mills
6. Subway engineering
7. Chemical plant
8. Ships
