Product Details
Compressed air contains contamination, in the form of water, oil and particles. It is therefore important that compressed air is filtered with a professional and economical compressed air filter element.
It also makes it possible to change filter elements more regularly. Which increases safety and minimizes energy costs.
Correct maintenance and regular replacement of elements ensure the functioning of the filters. This provides a continuous quality of the compressed air in your system, and thus a better and safer end product. Remember that even filters in new compressed air systems can be heavily contaminated.
Compressed air pollution comes, partly from the surroundings, and partly from the compression process. Water is a common component of the air around us. And water condenses automatically when the air is compressed. It is therefore important to post-treat and filter your compressed air before sending the compressed air further into your system.
There are often also both safety and environmental legal requirements for compressed air quality. Just as there are almost always quality requirements, both from customers, but also from quality assurance standards.
With compressed air filter elements from LVDA Filters, you are guaranteed a quality and advantageous compressed air filter element solution. This ensures that your compressed air system has a longer life, and that your product can meet the standards set for compressed air quality.
Product features
1.Quality-tested filter element for compressed air systems.
2.Tested and high quality.
3.Excellent filtration of oil, water and solid particles.
4.Robust alternative without compromising on quality.
Product parameters
Model: | BST-1400-CA |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | TS16949/ISO9001:2015 |
Efficiency: | 0.9999 |
Material: | Stainless Steel |
Quality: | 100% Tested |
End cap material: | Aluminium |
Diameter: | 120.00 mm |
Height: | 344.00 mm |
Differential pressure dry: | 60 mbar |
Operating temperature Min.: | 1,5 °C |
Operating temperature Max.: | 65 °C |
Flow direction: | Inside to outside |
Grade: | A |
Solid class: | 1 |
Oil class: | 0/1 |
Residual oil content: | 0.005 mg/m³ |
Product application
1.Automotive
2.Electronics
3.Food & Beverages
4.Chemical
5.Petrochemical
6.Plastics
7.Paint
8.General Industrial application
