Product Details
Air purification equipment is vital for the removal of system contamination.Air purification equipment is to remove air dash to keep compressor air clearance.
Oil filter is to remove contaminant from engine oil ,transmission oil,lubricating oil,hydraulic oil to keep oil tank clearance.
Oil air separator is separating the oil from compressor air filter parts ,make the compressed air cleaner and keep oil clean to return back oil tank.
Donaldson Filter Element, Model: MFP, UF Threaded Connection, 07/30 Element, 0.01 um, 480 cu-m/hr Flow Rate, 7 barg, 248 deg F Operating, Borosilicate Filter Media, 3.39 in ID, 8.11 in Overall Height
Product features
1.Expanded inner and outer stainless steel sleeves for the secure hold of the filter medium - no danger of corrosion, large openings ensure low differential pressure drop and high throughput
2.Binder-free depth filter medium made out of borosilicate glass fibers - low differential pressure drop, high throughput
3.Silicone-free version
Product parameters
Specifications |
Connection Type | UF Threaded |
Element Size | 07/30 |
Filter Media | Borosilicate |
Filtration Type | High Efficiency Filtration |
Flow Rate | 480 cu-m/hr |
Inside Diameter | 3.39 in |
Micron Rating | 0.01 Micron |
Model | MFP |
Operating Temperature | 248 deg F |
Overall Height | 8.11 in |
Pressure Rating | 7 barg |
Product Type | Genuine/OEM |
Attributes |
Certified for Painting Application | Yes |
Connection Type | UF Threaded End |
Diameter | 86 mm (3.39 inch) |
Efficiency 99.99998% | 0.01 micron |
Element O-Ring Material | Viton Labs-Free |
Element Size | Size 07/30 |
Element Type | AG, SG and HD Element |
End Cap Material | Aluminum |
Length | 206 mm (8.11 inch) |
Maximum Operating Temperature | 120 °C (248 °F) |
Media Type | Borosilicate |
Model | MFP |
Inner Core Material | 1.4301 / 304 Stainless Steel |
Oil Aerosol Retention Rate (ISO 12500-1) | 99.7 Percent |
Outer Core Material | 1.4301 / 304 Stainless Steel |
Recommended Replacement Interval | 8000 Hours |
Packaged Length | 0.22 M |
Packaged Width | 0.09 M |
Packaged Height | 0.09 M |
Packaged Weight | 0.4536 KG |
Packaged Volume | 0.001782 M3 |
Product application
1.Hotels,
2.Garment Shops,
3.Building Material Shops,
4.Manufacturing Plant,
5.Machinery Repair Shops,
6.Food & Beverage Factory,
7.Farms, Restaurant,
8.Home Use,
9.Retail,
10.Food Shop,
11.Printing Shops,
12.Construction works ,
13.Energy & Mining,
14.Food & Beverage Shops,
15.Advertising Company
