Product Details
Air Filter can be also called wind grid, inlet gnid, there are large amount of water, dust particle,oil mix in air. It will lead to pipeline corrosion and blockage and instrument mist& pneumatic equipment will be failed. Our filter could high efficiency remove impurities in air and make air clean, make sure equipment is normal operated.
Grade V/P - General Purpose Protection Particle removal down to 1 micron including coalesced liquid water and oil, providing a maximum remaining oil aerosol content of 0.6 mg/m3 (<0.5 ppm) @ 21°C.
Grade FP/M - High Efficiency Oil Removal Filtration
Particle removal down to 0.01 micron including water and oil aerosols, providing a maximum remaining oil aerosol content of 0.01 mg/m3 (<0.01 ppm) @ 21°C. (Precede with Grade GP filter).
Grade A - Activated Carbon Filtration
Oil vapour and hydrocarbon odour removal, giving a maximum remaining oil content of <0.003 mg/m3 (<0.003 ppm) (excluding methane) @ 21°C. (Precede Grade AC with Grade HE filter).
Test Standard
ISO 2941------Collapse & Burst Resistant
ISO 2942------Fabrication & Integrity Test
ISO 2943------Material Compatibility with Fluids
ISO3723------Method for end load test
ISO 3724------Flow Fatigue Characteristics
ISO 3968------Pressure Drop vs. Flow Rate
ISO 4572------Multi-pass Performance Testing
Product features
1.Good as original parts from factory.
2. Reliable quality with lower price, because we have the first hand source;
3.Covering a wide range, especially in OMI parts, larger stock, and shorter delivery time;
4.we can easily and quickly find the right part for you.
Product parameters
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Type: | Air filter, pre-filter element |
Filter material: | glassfiber, filter paper, activated carbon |
Filtration rating: | 1 micron |
Filter type: | Compressed air filter element |
Filtration efficiency: | 99.99% filtration area |
Application: | Air Compressor |
Certificate: | ISO9001:2008 |
Working time: | 5000h-8000h |
Product application
1.Hotels,
2.Garment Shops,
3.Building Material Shops,
4.Manufacturing Plant,
5.Machinery Repair Shops,
6.Food & Beverage Factory,
7.Farms,
8.Restaurant,
9.Home Use,
10.Retail,
11.Food Shop,
12.Printing Shops,
13.Construction works ,
14.Energy & Mining,
15.Food & Beverage Shops,
16.Advertising Company
