E381AC Activated Carbon Filter Element

Product Details

The E381AC is a high-efficiency Activated Carbon (AC) Grade filter element manufactured. It is specifically designed for industrial compressed air systems to ensure the highest air quality by removing

Technical Specifications

Filter Grade: AC (Activated Carbon / Adsorption)

Particle Removal: Down to 0.01 micron

Maximum Oil Carryover: 0.003 mg/m³ (0.003 ppm) at 20°C (68°F)

Maximum Working Pressure: 16 barg (232 psig)

Operating Temperature Range: Recommended up to 25°C (77°F) for optimal adsorption performance

Initial Differential Pressure: 75 mbar (1.1 psi)

Key Features & Construction

Deep Bed Adsorption: Utilizes a high-surface-area activated carbon medium to effectively adsorb gaseous oil and hydrocarbon odors.

Robust Build: Constructed with stainless steel internal and external cylinders for maximum structural integrity.

Push-fit Design: Features a double O-ring push-fit connection for easy installation and a leak-proof seal.

Flow Optimization: Designed to provide low pressure drop while maintaining high filtration efficiency, reducing energy costs.
