Product Details
Honeycomb filter element structure
The honeycomb filter element is neither a filter bag nor a filter cartridge in structure. This structure was first applied to the treatment of automobile exhaust particulates. Due to the narrow space inside the automobile, only compact and efficient filter elements can be used for treatment. The honeycomb filter element is designed to solve this problem. At present, the filtering technology has been transferred from the application of automobile exhaust to industrial dust treatment, and the ash removal system is configured to enable the whole system to operate continuously and reliably.
Honeycomb filter element is composed of several layers, each layer is evenly arranged with triangle strip filter tank, and each filter tank is bent by sheet filter material
One side of the filter is closed, and the other side is open and arranged in parallel. The dusty gas is driven by the pressure difference. After entering the triangle strip filter tank from the open end, the air flow filters the three sides of the filter material because the end is closed. The dust is trapped inside the filter tank, and the clean air is discharged from the open end of the adjacent triangle filter tank to complete the dust purification process.
At home and abroad, honeycomb dust collectors have been successfully put into use in many industries, including: welding dust treatment, plasma cutting dust treatment, mining industry dust treatment, metal processing dust treatment, tobacco industry dust treatment, wood processing industry dust treatment, grain industry dust treatment, etc.
Product features
1.Nano materials, higher precision and efficiency
2.Give your machine the first level of protection
3.Equal or higher than the original standard
4.high cost performance
Product parameters
Model: | 146397-10 |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | ISO9001 |
Quality: | 100% Tested |
Overall Height | 253.00 mm |
Outer Diameter | 175.00 mm |
Inner Diameter | 250.00 mm |
Parts Type | Air Filter |
Width: | 11.00 (in) |
Height: | 11.00 (in) |
Depth: | 4.00 (in) |
Weight: | 8.00 LBS |
Product application
1．Chemical and petrochemical industry
2．Pharmaceutical industry
3．Prefiltration of sterile filters
4．Filling machines
5．Food & beverage industry
6．Packing machines
7．Process industry
