Product Details
Air compressor filters, also called air line filters, are used in condensed air lines as a way to stop liquids and solid contaminants from entering air compressors. They stop these contaminants from entering the equipment and causing damage. A cubic foot of compressed air may harbor millions of dirt particles, in addition to significant amounts of oil and water. Depending on the application, the compressed air might even contain lead, mercury or other heavy metals.
Without air compressor filters removing such contaminants, the operation of critical system components, such as cylinders and valves, will be compromised. Air filtration is an essential element of proper compressed air preparation and can also prevent seals from swelling and experiencing premature wear. In addition to reducing downtime, clean compressed air results in lower energy costs.
Air Compressor Filter Usage and Maintenance
Compressed air filtration plays a hugely important role in any compressor installation. Having a high-quality air compressor filter will protect your system from particulates, dirt, dust, solid particles, and oil. Harmful contaminants like these can cause damage to your equipment and downstream machinery, wearing down parts and causing blockages.
Without a filter, contamination can even affect your manufactured product, causing loss of production and inevitably landing you with a hefty bill. Therefore, it is essential that high performing filters are used. Poor quality filters may offer a reduced performance, leading to large pressure drops and increasing your energy bill.
Product features
1.Strong, pliable gasket is compressed against the air cleaner housing to create a tight seal.
2.High-efficiency cellulose media performs across a wide range of heavy-duty engine applications.
3.Corrosion resistant, coated steel liners support media during operation and help maximize airflow.
4.Pleatloc™ feature ensures uniform pleat spacing and prevents media from bunching to promote longer service life.
Product parameters
Model: | P772523 |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | ISO9001 |
Quality: | 100% Tested |
Outer Diameter | 307.2 mm (12.09 inch) |
Inner Diameter | 196.2 mm (7.72 inch) |
Length | 411.5 mm (16.20 inch) |
Overall Length | 424.2 mm (16.70 inch) |
Bolt Hole Diameter | 16.76 mm (0.66 inch) |
Efficiency | 99.9 |
Efficiency Test Std | ISO 5011 |
Type | Primary |
Style | Round |
Media Type | Cellulose |
Product application
1.Mainly used for steel mill ,
2.power plant ,
3.mine/resource depot ,
4.paper mill,
5.paper making enterprise power hydraulic station system filtration,
6.petroleum,
7.metallurgy,
8.chemical industry,
9.railway,
10.oil field,
11.oil exploitation,
12.pharmaceutical factory aviation,
13.electronics,
14.power,
15.pharmaceutical,
16.environmental protection,
17.atomic energy,
18.nuclear industry,
19.natural gas,
20.refractory materials,
21.fire fighting equipment.
