Product Details
Mahler filter element is mainly used in the hydraulic system to filter solid particles and colloidal substances in the working medium, effectively control the pollution degree of the working medium and purify the medium. The materials used in the filter element are very easy to be damaged. Please pay attention to maintenance when using. Replace at any time to increase the service life. The larger particles in the filter medium can purify the materials, so that the machine and equipment can operate normally and improve the use efficiency.
The filtration accuracy of Mahler filter element refers to the filtration ability of the filter to remove particulate pollutants of different sizes. The commonly used filtration accuracy, filtration ratio, filtration efficiency and other indicators are evaluated. The filtration accuracy is divided into four grades: coarse (d ≥ 0.1mm), ordinary (d ≥ 0.01mm), fine (d20.005mm), and special fine (d ≥ 0.001 mm).
The filter in the hydraulic system of Mahler filter element is a kind of hydraulic resistance to the oil, so there must be a pressure drop when the oil passes. Generally speaking, when the size of the filter element and the oil flow rate are fixed, the higher the filtering accuracy of the filter element, the greater the pressure drop. When the flow rate is fixed, the larger the effective filtering area of the filter element, or the smaller the viscosity of the oil, the smaller the pressure drop.
Product features
1. LVDA Mahler hydraulic filter element has high porosity, good permeability, small resistance and low differential pressure. After the filter element is folded, the filtering area is large and the dirt holding capacity is large.
2. It has high temperature resistance, corrosion resistance and is suitable for filtering highly viscous liquid.
3. Mahle filter element has good regeneration performance, can be reused after chemical cleaning, high temperature and ultrasonic cleaning, and has wide chemical compatibility. It is your partner in the industrial filtration industry!
Product parameters
Model: | PI 8405 DRG 60 |
Place of Origin: | Henan, China |
Brand Name: | LVDA |
Life span: | 6000- 8000h |
Certificate: | ISO9001:2015 |
Quality: | 100% Tested |
Outer diameter | 47mm |
Height | 93mm |
inside diameter | 25.5mm |
intake diameter | 25.5mm |
material | wire mesh |
fineness | 60µm |
differential pressure resistance | 20 bars |
Product application
1.Metallurgy
2. Petrochemical
3. Textiles, electronics and pharmaceuticals
4. Power Plant
5. Steel mills
6. Subway engineering
7. Chemical plant
8.shipbuilding
9.Machinery manufacturing,
10.paper making
